Запчасти Komatsu 4D95L-W-1B ТОПЛ. НАСОС (НАСОС) (/) ТОПЛИВН. СИСТЕМА

|$0

6204-72-1330

INJECTION PUMP A.

SN: 11437-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.

-1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$3

DK101045-8050

PUMP ASS'Y

SN: 11437-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 AND 0452.

-1шт.

1

DK131034-1401

PLUG

SN: 11437-UP

4шт.

2

DK131152-4920

PLUNGER ASS'Y

SN: 11437-UP

4шт.

3

DK131110-3920

VALVE,DELIVERY

SN: 11437-UP

4шт.

4

DK131112-1600

SPRING

SN: 11437-UP

4шт.

5

DK131115-1600

GASKET

SN: 11437-UP

4шт.

6

DK131116-7600

HOLDER,DELIVERY VALVE

SN: 11437-UP

4шт.

7

DK131117-2300

STOPPER

SN: 11437-UP

4шт.

8

DK131122-0520

PLATE ASS'Y

SN: 11437-UP

2шт.

9

DK029632-0030

O-RING

SN: 11437-UP

4шт.

10

DK131200-0220

TAPPET ASS'Y

SN: 11437-UP

4шт.

11

DK131203-0200

PIN

SN: 11437-UP

1шт.

12

DK131204-1000

ROLLER

SN: 11437-UP

1шт.

13

DK131205-0500

BUSHING

SN: 11437-UP

1шт.

14

DK131206-0200

GUIDE

SN: 11437-UP

1шт.

15

DK029311-0580

SHIM, 0.2MM

SN: 11437-UP

-2шт.

15

DK029311-0590

SHIM, 0.25MM

SN: 11437-UP

-2шт.

15

DK029311-0020

SHIM, 0.30MM

SN: 11437-UP

-2шт.

15

DK029311-0600

SHIM, 0.35MM

SN: 11437-UP

-2шт.

15

DK029311-0030

SHIM, 0.40MM

SN: 11437-UP

-2шт.

15

DK029311-0610

SHIM, 0.45MM

SN: 11437-UP

-2шт.

15

DK029311-0040

SHIM, 0.50MM

SN: 11437-UP

-2шт.

15

DK029311-0270

SHIM, 0.55MM

SN: 11437-UP

-2шт.

15

DK029311-0050

SHIM, 0.6MM

SN: 11437-UP

-2шт.

15

DK029311-0280

SHIM, 0.65MM

SN: 11437-UP

-2шт.

15

DK029311-0060

SHIM, 0.7MM

SN: 11437-UP

-2шт.

15

DK029311-0290

SHIM, 0.75MM

SN: 11437-UP

-2шт.

15

DK029311-0070

SHIM, 0.8MM

SN: 11437-UP

-2шт.

15

DK029311-0310

SHIM, 0.85MM

SN: 11437-UP

-2шт.

15

DK029311-0080

SHIM, 0.9MM

SN: 11437-UP

-2шт.

15

DK029311-0320

SHIM, 0.95MM

SN: 11437-UP

-2шт.

15

DK029311-0090

SHIM, 1.0MM

SN: 11437-UP

-2шт.

15

DK029311-0330

SHIM, 1.05MM

SN: 11437-UP

-2шт.

15

DK029311-0110

SHIM, 1.1MM

SN: 11437-UP

-2шт.

15

DK029311-0340

SHIM, 1.15MM

SN: 11437-UP

-2шт.

15

DK029311-0120

SHIM, 1.2MM

SN: 11437-UP

-2шт.

15

DK029311-0350

SHIM, 1.25MM

SN: 11437-UP

-2шт.

15

DK029311-0130

SHIM, 1.3MM

SN: 11437-UP

-2шт.

15

DK029311-0620

SHIM, 1.35MM

SN: 11437-UP

-2шт.

15

DK029311-0140

SHIM, 1.4MM

SN: 11437-UP

-2шт.

15

DK029311-0630

SHIM, 1.45MM

SN: 11437-UP

-2шт.

15

DK029311-0490

SHIM, 1.5MM

SN: 11437-UP

-2шт.

15

DK029311-0710

SHIM, 1.55MM

SN: 11437-UP

-2шт.

15

DK029311-0500

SHIM, 1.6MM

SN: 11437-UP

-2шт.

16

DK131215-2500

SPRING,PLUNGER

SN: 11437-UP

4шт.

17

DK131216-0100

SEAT,SPRING

SN: 11437-UP

4шт.

18

DK131217-0200

SEAT,SPRING

SN: 11437-UP

4шт.

19

DK131254-0000

RACK,CONTROL

SN: 11437-UP

1шт.

20

DK131226-0300

SCREW

SN: 11437-UP

1шт.

21

DK131240-0100

PINION

SN: 11437-UP

4шт.

22

DK131241-0100

SLEEVE,CONTROL

SN: 11437-UP

4шт.

23

DK131242-0100

SCREW

SN: 11437-UP

4шт.
