Артикул
Название
Примечание
Количество
|1
6731-71-1390
INJECTION PUMP A.
SN: 26244267-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A401P-02A4 TO A401P-06A4.
-1шт.
|1
DK101041-9260
PUMP ASS'Y
SN: 26244267-UP
1шт.
|$$4
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A401P-02A4 AND A401P-03A4.
-1шт.
1
DK131067-5620
HOUSING
SN: 26244267-UP
1шт.
2
DK029040-6020
STUD
SN: 26244267-UP
3шт.
3
DK134026-0000
PLUG
SN: 26244267-UP
1шт.
4
DK131002-2000
ADAPTER
SN: 26244267-UP
2шт.
5
DK131028-6220
COVER
SN: 26244267-UP
1шт.
6
DK131011-1900
GASKET
SN: 26244267-UP
1шт.
7
DK131017-1000
SCREW
SN: 26244267-UP
2шт.
9
DK139206-0400
NUT
SN: 26244267-UP
3шт.
11
DK131361-2700
CAMSHAFT
SN: 26244267-UP
1шт.
|12
DK028201-7020
BEARING
SN: 26244267-UP
-2шт.
13
DK016640-2030
BEARING
SN: 26244267-UP
-2шт.
|13
DK028202-0020
BEARING
SN: 26244267-UP
-2шт.
14
DK131302-1300
RING
SN: 26244267-UP
1шт.
15
DK131302-0300
RING
SN: 26244267-UP
1шт.
16
DK029312-0310
SHIM¤ 0.10MM
SN: 26244267-UP
-2шт.
|16
DK029312-0320
SHIM¤ 0.12MM
SN: 26244267-UP
-2шт.
|16
DK029312-0330
SHIM¤ 0.14MM
SN: 26244267-UP
-2шт.
|16
DK029312-0340
SHIM¤ 0.16MM
SN: 26244267-UP
-2шт.
|16
DK029312-0350
SHIM¤ 0.18MM
SN: 26244267-UP
-2шт.
|16
DK029312-0360
SHIM¤ 0.3MM
SN: 26244267-UP
-2шт.
|16
DK029312-0370
SHIM¤ 0.5MM
SN: 26244267-UP
-2шт.
|16
DK029312-0380
SHIM¤ 1.0MM
SN: 26244267-UP
-2шт.
17
DK029311-7010
SHIM¤ 0.1MM
SN: 26244267-UP
-2шт.
|17
DK029311-7020
SHIM¤ 0.12MM
SN: 26244267-UP
-2шт.
|17
DK029311-7030
SHIM¤ 0.14MM
SN: 26244267-UP
-2шт.
|17
DK029311-7040
SHIM¤ 0.16MM
SN: 26244267-UP
-2шт.
|17
DK029311-7050
SHIM¤ 0.18MM
SN: 26244267-UP
-2шт.
|17
DK029311-7090
SHIM¤ 0.3MM
SN: 26244267-UP
-2шт.
|17
DK029311-7060
SHIM¤ 0.5MM
SN: 26244267-UP
-2шт.
|17
DK029311-7210
SHIM¤ 0.7MM
SN: 26244267-UP
-2шт.
|17
DK029311-7070
SHIM¤ 1.0MM
SN: 26244267-UP
-2шт.
|17
DK029311-7220
SHIM¤ 1.4MM
SN: 26244267-UP
-2шт.
|17
DK139417-0000
SHIM¤ 2.40MM
SN: 26244267-UP
-2шт.
18
DK029622-0190
SEAL,OIL
SN: 26244267-UP
1шт.
19
DK131330-6400
COVER
SN: 26244267-UP
1шт.
20
DK029010-6810
BOLT
SN: 26244267-UP
4шт.
21
DK131321-1900
GASKET
SN: 26244267-UP
1шт.
23
DK131401-0020
BOLT
SN: 26244267-UP
1шт.
|1
6731-71-1390
INJECTION PUMP A.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A401P-02A4 TO A401P-06A4.
|1
DK101041-9260
PUMP ASS'Y
|$$4
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A401P-02A4 AND A401P-03A4.
1
DK131067-5620
HOUSING
2
DK029040-6020
STUD
3
DK134026-0000
PLUG
4
DK131002-2000
ADAPTER
5
DK131028-6220
COVER
6
DK131011-1900
GASKET
7
DK131017-1000
SCREW
8
DK029340-6020
GASKET
9
DK139206-0400
NUT
10
DK029633-1010
O-RING
11
DK131361-2700
CAMSHAFT
12
DK016630-2030
BEARING
|12
DK028201-7020
BEARING
13
DK016640-2030
BEARING
|13
DK028202-0020
BEARING
14
DK131302-1300
RING
15
DK131302-0300
RING
16
DK029312-0310
SHIM¤ 0.10MM
|16
DK029312-0320
SHIM¤ 0.12MM
|16
DK029312-0330
SHIM¤ 0.14MM
|16
DK029312-0340
SHIM¤ 0.16MM
|16
DK029312-0350
SHIM¤ 0.18MM
|16
DK029312-0360
SHIM¤ 0.3MM
|16
DK029312-0370
SHIM¤ 0.5MM
|16
DK029312-0380
SHIM¤ 1.0MM
17
DK029311-7010
SHIM¤ 0.1MM
|17
DK029311-7020
SHIM¤ 0.12MM
|17
DK029311-7030
SHIM¤ 0.14MM
|17
DK029311-7040
SHIM¤ 0.16MM
|17
DK029311-7050
SHIM¤ 0.18MM
|17
DK029311-7090
SHIM¤ 0.3MM
|17
DK029311-7060
SHIM¤ 0.5MM
|17
DK029311-7210
SHIM¤ 0.7MM
|17
DK029311-7070
SHIM¤ 1.0MM
|17
DK029311-7220
SHIM¤ 1.4MM
|17
DK139417-0000
SHIM¤ 2.40MM
18
DK029622-0190
SEAL,OIL
19
DK131330-6400
COVER
20
DK029010-6810
BOLT
21
DK131321-1900
GASKET
22
DK131424-3420
VALVE,OVER FLOW
23
DK131401-0020
BOLT
24
DK029341-4130
GASKET
25
DK029637-5030
O-RING
26
DK029731-0120
BOLT,EYE
27
DK029341-0110
GASKET
