Запчасти Komatsu 4D102E-1C-US ГОЛОВКА ЦИЛИНДРОВ(№7-) ДВИГАТЕЛЬ

|1

6731-11-1011

HEAD ASS'Y

SN: 26237230-UP

1шт.

1

0

HEAD

SN: 26237230-UP

1шт.

2

6736-11-1150

PLUG

SN: 26200282-UP

3шт.

3

6732-11-1170

INSERT,EXHAUST

SN: 26200282-UP

4шт.

4

6732-11-1180

INSERT,INTAKE

SN: 26200282-UP

4шт.

5

6732-11-1910

PLUG

SN: 26200282-UP

5шт.

6

6732-11-1930

PLUG

SN: 26200282-UP

2шт.

7

6732-41-4530

SEAL,EXHAUST

SN: 26200282-26254027

4шт.

8

6732-41-4540

SEAL

SN: 26254028-UP

8шт.

|8

6732-41-4540

SEAL,INTAKE

SN: 26200282-26254027

4шт.

|9

6736-41-4110

INTAKE VALVE ASS'Y

SN: 26200282-UP

4шт.

9

0

VALVE

SN: 26200282-UP

1шт.

10

6732-41-4520

COTTER

SN: 26200282-UP

2шт.

|11

6736-41-4210

EXHAUST VALVE ASS'Y

SN: 26200282-UP

4шт.

11

0

VALVE

SN: 26200282-UP

1шт.

12

6732-41-4520

COTTER

SN: 26200282-UP

2шт.

13

6732-41-4410

SPRING

SN: 26200282-UP

8шт.

14

6731-41-4510

RETAINER

SN: 26254028-UP

8шт.

|14

0

RETAINER

SN: 26200282-26254027

8шт.

15

6732-11-1610

BOLT

SN: 26200282-UP

4шт.

16

6732-11-1620

BOLT

SN: 26200282-UP

10шт.

17

6732-11-1151

GASKET

SN: 26237230-UP

1шт.

|$$23

REFER TO FIG. NOS. OF REPAIR PARTS FOR O.S.¤ U.S.¤ AND SERVICE PARTS.

-1шт.

|1

6731-11-1011

HEAD ASS'Y

1

HEAD

2

6736-11-1150

PLUG

3

6732-11-1170

INSERT,EXHAUST

4

6732-11-1180

INSERT,INTAKE

5

6732-11-1910

PLUG

6

6732-11-1930

PLUG

7

6732-41-4530

SEAL,EXHAUST

8

6732-41-4540

SEAL

|8

6732-41-4540

SEAL,INTAKE

|9

6736-41-4110

INTAKE VALVE ASS'Y

9

VALVE

10

6732-41-4520

COTTER

|11

6736-41-4210

EXHAUST VALVE ASS'Y

11

VALVE

12

6732-41-4520

COTTER

13

6732-41-4410

SPRING

14

6731-41-4510

RETAINER

|14

6732-41-4510

RETAINER

15

6732-11-1610

BOLT

16

6732-11-1620

BOLT

17

6732-11-1151

GASKET

|$$23

REFER TO FIG. NOS. OF REPAIR PARTS FOR O.S.¤ U.S.¤ AND SERVICE PARTS.
