Запчасти Komatsu 3D84N-1YC ГЕНЕРАТОР ЭЛЕКТРИКА

|1

YM124080-77201

ALTERNATOR ASS'Y

SN: 20425-UP

1шт.

1

YMX-L13511001

ROTOR ASS'Y

SN: 20425-UP

1шт.

2

YMX-6201SD

BEARING

SN: 20425-UP

1шт.

|3

YMX-L12053002

REAR COVER ASS'Y

SN: 20425-UP

1шт.

3

YMX-L12033011

COVER

SN: 20425-UP

1шт.

4

YMX-L13513152

BRUSH ASS'Y

SN: 20425-UP

1шт.

5

YMX-L1354326

BRUSH ASS'Y

SN: 20425-UP

1шт.

6

YMX-L12013262

BRUSH

SN: 20425-UP

2шт.

7

YMX-TR1Z63

REGULATOR ASS'Y

SN: 20425-UP

1шт.

8

YMX-L13513134

BOLT

SN: 20425-UP

2шт.

9

YMX-L13513203

DIODE ASS'Y

SN: 20425-UP

1шт.

10

YMX-L1356360

WIRE ASS'Y

SN: 20425-UP

1шт.

11

YMX-L1356200

STATOR ASS'Y

SN: 20425-UP

1шт.

12

YMX-L1202401

FRONT COVER ASS'Y

SN: 20425-UP

1шт.

13

YMX-6202BM

BEARING

SN: 20425-UP

1шт.

14

YMX-L13514041

RETAINER

SN: 20425-UP

1шт.

15

YMX-L12010001

SCREW ASS'Y

SN: 20425-UP

1шт.

16

YMX-L1201510

PULLEY ASS'Y

SN: 20425-UP

1шт.

17

YMX-B495469B

NUT ASS'Y

SN: 20425-UP

1шт.

18

YMX-L1254801

BOLT

SN: 20425-UP

2шт.

19

YMX-L1255801

BOLT

SN: 20425-UP

1шт.
