Артикул
Название
Примечание
Количество
|1
YM729210-51380
INJECTION PUMP ASS'Y
SN: 05993-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B0A1 TO A4010-E0A1.
-1шт.
1
YM129506-51100
PLUNGER ASS'Y
SN: 05993-UP
3шт.
2
YM129155-51140
PIN
SN: 05993-UP
3шт.
3
YM174307-51170
SEAT
SN: 05993-UP
3шт.
4
YM129155-51180
RETAINER
SN: 05993-UP
3шт.
6
YM129155-51200
TAPPET ASS'Y
SN: 05993-UP
3шт.
7
YM129155-51270
STOPPER
SN: 05993-UP
3шт.
8
YM129155-51280
O-RING
SN: 05993-UP
3шт.
9
YM129505-51300
VALVE,DELIVERY
SN: 05993-UP
3шт.
11
YM129155-51340
HOLDER
SN: 05993-UP
3шт.
12
YM124550-51350
GASKET
SN: 05993-UP
3шт.
14
YM129155-51370
STOPPER
SN: 05993-UP
3шт.
15
YM129155-51380
STOPPER
SN: 05993-UP
2шт.
16
YM129155-51390
STOPPER
SN: 05993-UP
2шт.
17
YM129155-51400
DEFLECTOR
SN: 05993-UP
1шт.
18
YM129155-51410
BOLT
SN: 05993-UP
1шт.
19
YM129155-51420
PLUG
SN: 05993-UP
1шт.
20
YM129155-51500
RACK,CONTROL
SN: 05993-UP
1шт.
21
YM129155-51521
BUSHING
SN: 05993-UP
1шт.
22
YM129155-51530
SPACER
SN: 05993-UP
1шт.
23
YM129155-51540
RING
SN: 05993-UP
1шт.
24
YM129155-51550
PINION,CONTROL
SN: 05993-UP
3шт.
25
YM122117-51560
SCREW
SN: 05993-UP
3шт.
26
YM174307-51560
PINION
SN: 05993-UP
3шт.
27
YM129155-51570
PLUG
SN: 05993-UP
1шт.
28
YM129155-51580
O-RING
SN: 05993-UP
1шт.
29
YM129155-51591
SPRING
SN: 05993-UP
1шт.
30
YM129155-51600
SHIM ASS'Y
SN: 05993-UP
3шт.
31
YM129155-51790
STOPPER
SN: 05993-UP
1шт.
32
YM22217-050000
WASHER,SPRING
SN: 05993-UP
2шт.
33
YM24341-000160
O-RING
SN: 05993-UP
1шт.
34
YM26116-050302
BOLT
SN: 05993-UP
2шт.
35
YM22190-160002
SEAL,RING
SN: 05993-UP
1шт.
|1
YM729210-51380
INJECTION PUMP ASS'Y
SN: 05993-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B0A1 TO A4010-E0A1.
-1шт.
1
YM129506-51100
PLUNGER ASS'Y
SN: 05993-UP
3шт.
2
YM129155-51140
PIN
SN: 05993-UP
3шт.
3
YM174307-51170
SEAT
SN: 05993-UP
3шт.
4
YM129155-51180
RETAINER
SN: 05993-UP
3шт.
6
YM129155-51200
TAPPET ASS'Y
SN: 05993-UP
3шт.
7
YM129155-51270
STOPPER
SN: 05993-UP
3шт.
8
YM129155-51280
O-RING
SN: 05993-UP
3шт.
9
YM129505-51300
VALVE,DELIVERY
SN: 05993-UP
3шт.
11
YM129155-51340
HOLDER
SN: 05993-UP
3шт.
12
YM124550-51350
GASKET
SN: 05993-UP
3шт.
14
YM129155-51370
STOPPER
SN: 05993-UP
3шт.
15
YM129155-51380
STOPPER
SN: 05993-UP
2шт.
16
YM129155-51390
STOPPER
SN: 05993-UP
2шт.
17
YM129155-51400
DEFLECTOR
SN: 05993-UP
1шт.
18
YM129155-51410
BOLT
SN: 05993-UP
1шт.
19
YM129155-51420
PLUG
SN: 05993-UP
1шт.
20
YM129155-51500
RACK,CONTROL
SN: 05993-UP
1шт.
21
YM129155-51521
BUSHING
SN: 05993-UP
1шт.
22
YM129155-51530
SPACER
SN: 05993-UP
1шт.
23
YM129155-51540
RING
SN: 05993-UP
1шт.
24
YM129155-51550
PINION,CONTROL
SN: 05993-UP
3шт.
25
YM122117-51560
SCREW
SN: 05993-UP
3шт.
26
YM174307-51560
PINION
SN: 05993-UP
3шт.
27
YM129155-51570
PLUG
SN: 05993-UP
1шт.
28
YM129155-51580
O-RING
SN: 05993-UP
1шт.
29
YM129155-51591
SPRING
SN: 05993-UP
1шт.
30
YM129155-51600
SHIM ASS'Y
SN: 05993-UP
3шт.
31
YM129155-51790
STOPPER
SN: 05993-UP
1шт.
32
YM22217-050000
WASHER,SPRING
SN: 05993-UP
2шт.
33
YM24341-000160
O-RING
SN: 05993-UP
1шт.
34
YM26116-050302
BOLT
SN: 05993-UP
2шт.
35
YM22190-160002
SEAL,RING
SN: 05993-UP
1шт.
Выбрано товаров: 74
