Запчасти Komatsu 3D84E-3D БЛОК ЦИЛИНДРОВ(№-) БЛОК ЦИЛИНДРОВ

|1

YM729002-01560

CYLINDER BLOCK ASS'Y

SN: 03304-UP

1шт.

1

0

BLOCK ASS'Y

SN: 03304-UP

1шт.

2

YM124160-01910

PLUG

SN: 03304-UP

3шт.

3

YM23871-010000

PLUG

SN: 03304-UP

1шт.

4

YM171051-01921

PLUG

SN: 03304-UP

1шт.

5

YM27231-500000

PLUG

SN: 03304-UP

1шт.

6

YM27241-120000

PLUG

SN: 03304-UP

2шт.

7

YM27241-300000

PLUG

SN: 03304-UP

6шт.

8

YM129795-02411

BUSHING

SN: 03304-UP

1шт.

9

YM129001-02800

MAIN METAL ASS'Y (STD)

SN: 03304-UP

4шт.

|9

YM129150-02870

MAIN METAL ASS'Y,0.25MM (US)

SN: 03304-UP

4шт.

10

YM129150-02930

THRUST METAL ASS'Y (STD)

SN: 03304-UP

2шт.

|10

YM129150-02940

THRUST METAL ASS'Y,0.25MM (OS)

SN: 03304-UP

2шт.

11

YM129150-02020

BOLT

SN: 03304-UP

8шт.

12

YM119260-34810

GUIDE

SN: 03304-UP

1шт.

13

YM129136-34820

GUIDE

SN: 03304-UP

1шт.

14

YM24311-240100

O-RING

SN: 03304-UP

2шт.

15

YM129128-34800

GAUGE,OIL LEVEL

SN: 03304-UP

1шт.

16

YM171056-49120

PLUG,DRAIN

SN: 03304-UP

1шт.
