Запчасти Komatsu 3D84E-3D ТОПЛ. НАСОС (РЕГУЛЯТОР) (/)(№-) ТОПЛИВН. СИСТЕМА

1

YM729210-51360

INJECTION PUMP ASS'Y

SN: 03304-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0453 TO 0464.

-1шт.

2

YM23887-100002

PLUG

SN: 03304-UP

1шт.

3

YM22190-100002

SEAL,SEAL

SN: 03304-UP

1шт.

4

YM129052-61060

COVER

SN: 03304-UP

1шт.

5

YM129052-61070

GASKET

SN: 03304-UP

1шт.

6

YM26106-060102

BOLT

SN: 03304-UP

4шт.

7

YM129155-61450

BOLT,ADJUSTING

SN: 03304-UP

1шт.

8

YM124550-66370

NUT

SN: 03304-UP

1шт.

9

YM129155-61470

BOLT,ADJUSTING

SN: 03304-UP

1шт.

10

YM26776-120002

NUT

SN: 03304-UP

1шт.

11

YM26687-120002

NUT,CAP

SN: 03304-UP

1шт.

12

YM22190-120002

SEAL,WASHER

SN: 03304-UP

2шт.

13

YM129100-61400

SHAFT ASS'Y

SN: 03304-UP

1шт.

14

YM129155-61830

O-RING

SN: 03304-UP

1шт.

15

YM129100-61440

LEVER,CONTROL

SN: 03304-UP

1шт.

16

YM129155-61430

SPACER

SN: 03304-UP

1шт.

17

YM26366-080002

NUT

SN: 03304-UP

1шт.

18

YM129155-61460

BOLT,ADJUSTING

SN: 03304-UP

1шт.

19

YM26756-060002

NUT

SN: 03304-UP

1шт.

20

YM171353-61710

SPRING,GOVERNOR

SN: 03304-UP

1шт.

21

YM119233-77930

SOLENOID,ENGINE STOP

SN: 03304-UP

1шт.

22

YM26106-060142

BOLT

SN: 03304-UP

2шт.

23

YM24341-000280

O-RING

SN: 03304-UP

1шт.

24

YM26106-060102

BOLT

SN: 03304-UP

1шт.

25

YM22190-060002

GASKET,SEAL

SN: 03304-UP

1шт.

26

YM129052-61050

GASKET

SN: 03304-UP

1шт.

27

YM129155-61950

BOLT

SN: 03304-UP

1шт.

28

YM26106-060202

BOLT

SN: 03304-UP

6шт.

29

YM135210-61090

LEAD

SN: 03304-UP

1шт.

30

YM22451-060000

WIRE

SN: 03304-UP

1шт.
