Запчасти Komatsu 210M QSK19 Engine LUBE МАСЛ. ФИЛЬТР & КРЕПЛЕНИЕ СИСТЕМА СМАЗКИ МАСЛ. СИСТЕМА

1

1239 759 H1

BOLT (3/8 - 16x1 1/4 INCH)

6шт.

2

1307 846 H1

GASKET, LUBE OIL FILTER COVER

1шт.

|$2

1307 847 H91

ELBOW, MALE UNION

1шт.

3

1246 119 H1

SEAL, O RING

1шт.

4

1307 848 H1

ELBOW, MALE UNION

1шт.

5

1307 210 H1

SEAL, O RING

2шт.

|$6

1307 849 H91

HEAD, LUBE OIL FILTER

1шт.

6

1241 103 H1

BOLT

8шт.

7

1246 127 H1

PIN, ROLL

2шт.

|$9

1246 118 H91

PLUG, THREADED

5шт.

3

1246 119 H1

SEAL, O RING

1шт.

8

1246 120 H1

PLUG, THREADED

1шт.

9

1307 850 H1

WASHER, PLAIN

8шт.

10

1307 851 H1

SEAL, O RING

2шт.

11

1307 852 H1

PLUNGER, FILTER HEAD

2шт.

|$15

1307 853 H91

PLUG, THREADED

2шт.

12

1294 142 H1

SEAL, O RING

1шт.

13

1307 854 H1

PLUG, THREADED

1шт.

14

1307 855 H1

HEAD, LUBE OIL FILTER

1шт.

15

1307 856 H1

ADAPTER, FILTER HEAD

2шт.

16

1307 857 H1

SEAL, O RING

2шт.

17

1307 858 H1

SEAL, O RING

2шт.

18

1307 859 H1

SPRING, VALVE

2шт.

|$23

1307 860 H91

ELBOW, FEMALE ADAPTER

1шт.

3

1246 119 H1

SEAL, O RING

1шт.

19

1307 861 H1

ELBOW, PLAIN UNION

1шт.

|$26

1307 862 H91

VALVE, CHECK

1шт.

20

1307 863 H1

VALVE, CHECK

1шт.

21

1307 210 H1

SEAL, O RING

2шт.

|$29

1239 920 H1

PLUG, THREADED

2шт.

22

1296 161 H1

PLUG, THREADED

1шт.

23

1241 538 H1

SEAL, O RING

1шт.

24

1307 864 H1

HOSE, FLEXIBLE

1шт.

25

1295 224 H1

FILTER, LUBE OIL

2шт.
