Запчасти Komatsu 210M QSK19 Engine ПОРШЕНЬ & ШАТУН БЛОК ЦИЛИНДРОВ

1

1238 737 H1

BEARING, CONNECTING ROD

12шт.

|$1

1238 738 H1

BEARING, CONNECTING ROD - .010 OVERSIZE

-2шт.

|$2

1238 739 H1

BEARING, CONNECTING ROD - .020 OVERSIZE

-2шт.

|$3

1238 740 H1

BEARING, CONNECTING ROD - .030 OVERSIZE

-2шт.

|$4

1310 479 H1

ROD, ENGINE CONNECTING

6шт.

2

1240 038 H1

DOWEL, PIN

4шт.

3

1238 668 H1

WASHER, PLAIN (5/8 INCH)

2шт.

4

NSS

ROD, ENGINE CONNECTING

1шт.

5

1239 291 H1

BOLT

2шт.

6

1239 784 H1

BUSHING

1шт.

|$10

1310 353 H91

SET, PISTON RING

6шт.

7

1307 924 H1

RING, COMPRESSION PISTON

1шт.

8

1242 051 H1

RING, COMPRESSION PISTON

1шт.

9

1307 925 H1

RING, OIL PISTON

1шт.

|$14

1310 480 H91

KIT, ENGINE PISTON

6шт.

10

1238 703 H1

RING, RETAINING

12шт.

11

1307 926 H1

PIN, PISTON

6шт.

|$17

1310 481 H91

PISTON, ENGINE TLA

6шт.

|$18

1307 928 H91

TOP, PISTON

1шт.

12

NSS

BUSHING

2шт.

13

NSS

TOP, PISTON

1шт.

14

1307 931 H1

SKIRT, PISTON

1шт.

|$$23

-1шт.

|$23

R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED

-1шт.

|$24

ASSEMBLIES CATALOG.

-1шт.
