Запчасти Komatsu 210M QSK19 Engine МАСЛЯНЫЙ ПОДДОН БЛОК ЦИЛИНДРОВ

1

1241 299 H1

BOLT (1/2 - 20 x 3/4 INCH)

1шт.

2

SG 0 438

BOLT (3/8 - 24 x 1 1/4 INCH)

1шт.

3

SD 0 054

WASHER, LOCK (7/16 INCH)

2шт.

4

25 544

WASHER, PLAIN (3/8 INCH)

4шт.

5

1238 250 H1

NUT, LOCK (3/8 - 24 UNF)

1шт.

6

1294 535 H1

WASHER, SEALING

1шт.

7

1239 212 H1

BOLT (3/8 - 16 x 1 INCH)

1шт.

8

1239 265 H1

BOLT (3/8 - 16 x 3/4 INCH)

1шт.

9

1241 337 H1

BOLT (3/8 - 16 x 1 1/2 INCH)

28шт.

10

1239 759 H1

BOLT (3/8 - 16 x 1 1/4 INCH)

18шт.

11

1239 771 H1

GASKET, OIL PAN

1шт.

|$11

1246 131 H91

PLUG, THREADED (3/4 - 16 UNF)

2шт.

12

1246 132 H1

PLUG, THREADED

2шт.

13

1240 473 H1

SEAL, O-RING

2шт.

|$14

1241 619 H91

PLUG, THREADED

2шт.

14

1241 502 H1

PLUG, THREADED (1 1/16 - 12 UN)

2шт.

15

1241 503 H1

SEAL, O-RING

2шт.

16

1241 745 H91

COVER, OIL PAN ADAPTER

1шт.

17

1241 379 H2

GASKET, ADAPTER

1шт.

18

1307 881 H1

GASKET, OIL SUCTION CONNECTION

1шт.

19

1307 882 H1

BOLT

2шт.

20

1307 885 H1

CLIP

2шт.

21

1310 113 H1

PAN, OIL

1шт.

22

1310 115 H1

BRACE, TUBE

1шт.

23

1310 565 H1

TUBE, LUBE OIL SUCTION

1шт.

|$25

1239 920 H1

PLUG, THREADED

2шт.

24

1296 161 H1

PLUG, THREADED

1шт.

25

1241 538 H1

SEAL, O-RING

1шт.
