Запчасти Komatsu L700D Turbo ТУРБОНАГНЕТАТЕЛЬ ДВИГАТЕЛЬ, АКСЕССУАРЫ И ЭЛЕКТРИЧ. СИСТЕМА

1

2872893M91

TURBOCHARGER

DeutschDesc: TURBOLADER

1шт.

2

2872888M1

HOUSING

DeutschDesc: GEHAEUSE

1шт.

3

2872889M1

BAND

DeutschDesc: BAND

1шт.

4

2962331M1

NUT

DeutschDesc: MUTTER

1шт.

5

2872867M1

IMPELLER

EnglischBem: NOTE: Pos. (5) included in Pos. (1) (31) and (33) Kit

1шт.

6

2872868M1

PISTON RING

EnglischBem: NOTE: Pos. (6) included in Pos. (1) (31) and (32) Kit

1шт.

7

2872866M1

RACE

EnglischBem: NOTE: Pos. (7) included in Pos. (1) (31) and (32) Kit

1шт.

8

2872865M1

BEARING

EnglischBem: NOTE: Pos. (8) included in Pos. (1) (31) and (32) Kit

2шт.

9

2872864M1

CIRCLIP

EnglischBem: NOTE: Pos. (9) included in Pos. (1) (31) and (32) Kit

3шт.

10

2872863M1

HOUSING

EnglischBem: NOTE: Pos. (10) included in Pos. (1) and (31) Kit

1шт.

11

2872869M1

SHEET

EnglischBem: NOTE: Pos. (11) included in Pos. (1) and (31) Kit

1шт.

12

2872870M1

BUSHING

EnglischBem: NOTE: Pos. (12) included in Pos. (1) (31) and (33) Kit

2шт.

13

2872871M1

BUSHING

EnglischBem: NOTE: Pos. (13) included in Pos. (1) (31) and (33) Kit

1шт.

14

2872872M1

BEARING

EnglischBem: NOTE: Pos. (14) included in Pos. (1) (31) and (32) Kit

1шт.

15

3004678X1

SCREW

EnglischBem: NOTE: Pos. (15) included in Pos. (1) (31) and (32) Kit

3шт.

16

2872876M1

DISC

EnglischBem: NOTE: Pos. (16) included in Pos. (1) (31) and (32) Kit

3шт.

17

2872875M1

FENDER

EnglischBem: NOTE: Pos. (17) included in Pos. (1) and (31) Kit

1шт.

18

2872873M1

BUSHING

EnglischBem: NOTE: Pos. (18) included in Pos. (1) (31) and (33) Kit

1шт.

19

2872874M1

PISTON RING

EnglischBem: NOTE: Pos. (19) included in Pos. (1) (31) and (32) Kit

2шт.

20

2872878M1

GASKET

EnglischBem: NOTE: Pos. (20) included in Pos. (1) (31) and (32) Kit

1шт.

21

2872879M1

COVER

EnglischBem: NOTE: Pos. (21) included in Pos. (1) and (31) Kit

1шт.

22

2872880M1

CIRCLIP

EnglischBem: NOTE: Pos. (22) included in Pos. (1) and (31) Kit

1шт.

23

2872881M1

DISC

EnglischBem: THICKNESS 0,05MM NOTE: Pos. (23) included in Pos. (1) (31) and (

-26шт.

24

2872882M1

DISC

EnglischBem: THICKNESS 0,15 MM NOTE: Pos. (24) included in Pos. (31) and (32)

-26шт.

25

2872883M1

DISC

EnglischBem: THICKNESS 0,25 MM NOTE: Pos. (25) included in Pos. (1) (31) and

-26шт.

26

2872884M1

IMPELLER

EnglischBem: NOTE: Pos. (26) included in Pos. (1) (31) and (33) Kit

1шт.

27

2872885M1

NUT

EnglischBem: NOTE: Pos. (27) included in Pos. (1) (31) and (32) Kit

1шт.

28

1444889X1

SCREW

EnglischBem: NOTE: Pos. (28) included in Pos. (1) and (32) Kit

6шт.

29

3000146X1

CUP SPRING

EnglischBem: NOTE: Pos. (29) included in Pos. (1) and (32) Kit

6шт.

30

2872886M1

HOUSING

DeutschDesc: GEHAEUSE

1шт.

31

2872900M91

REPAIR KIT

DeutschDesc: REPARATURSATZ

1шт.

32

2872898M91

REPAIR KIT

DeutschDesc: REPARATURSATZ

1шт.

33

2872899M91

REPAIR KIT

DeutschDesc: REPARATURSATZ

1шт.
