Komatsu
/
Бульдозеры гусеничные
/
L600D Super S/N 332720001 - Up
/
ОБОРУД-Е
/

GRAB КОВШ

Запчасти Komatsu L600D Super GRAB КОВШ ОБОРУД-Е

Схема запчастей Komatsu L600D Super - GRAB КОВШ ОБОРУД-Е
2
1
26
25
19
11
12
22
21
10
3
11
24
13
23
15
14
19
17
19
18
7
20
8
25
16
9
6
4
5
29
30
28
31
27

№

Артикул

Название

Примечание

Количество

1

4000175M91

BUCKET

EnglischBem: WITHOUT TEETH 1,6 CBM

1шт.

2

4000174M91

BUCKET

EnglischBem: 1,6 CBM

1шт.

3

3254081M91

BUCKET

EnglischBem: NOTE: Pos. (3) included in Pos. (1) and (2) Kit

1шт.

4

2975720M91

GRAB JAW

EnglischBem: NOTE: Pos. (4) included in Pos. (1) and (2) Kit

1шт.

5

2975721M1

STIRRUP

EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (2) Kit

1шт.

6

2975722M1

CUTTING EDGE

EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (2) Kit

1шт.

7

2975723M1

SCREW

EnglischBem: NOTE: Pos. (7) included in Pos. (1) and (2) Kit

14шт.

8

2975724M1

SPRING WASHER

EnglischBem: NOTE: Pos. (8) included in Pos. (1) and (2) Kit

14шт.

9

2975725M1

NUT

EnglischBem: NOTE: Pos. (9) included in Pos. (1) and (2) Kit

14шт.

10

2975726M1

CUTTING EDGE

EnglischBem: NOTE: Pos. (10) included in Pos. (1) and (2) Kit

1шт.

11

2975727M1

CORNER CUTTER

EnglischBem: NOTE: Pos. (11) included in Pos. (1) and (2) Kit

2шт.

12

2975728M1

SCREW

EnglischBem: NOTE: Pos. (12) included in Pos. (1) and (2) Kit

16шт.

13

2975729M1

SPRING WASHER

EnglischBem: NOTE: Pos. (13) included in Pos. (1) and (2) Kit

16шт.

14

2975730M1

DISC

EnglischBem: NOTE: Pos. (14) included in Pos. (1) and (2) Kit

16шт.

15

2975731M1

NUT

EnglischBem: NOTE: Pos. (15) included in Pos. (1) and (2) Kit

16шт.

16

3241015M1

BUSHING

EnglischBem: NOTE: Pos. (16) included in Pos. (1) and (2) Kit

4шт.

17

2975734M1

PIN

EnglischBem: NOTE: Pos. (17) included in Pos. (1) and (2) Kit

2шт.

18

2975735M1

PIN

EnglischBem: NOTE: Pos. (18) included in Pos. (1) and (2) Kit

2шт.

19

2975736M1

ELECTRICAL PLUG

EnglischBem: NOTE: Pos. (19) included in Pos. (1) and (2) Kit

6шт.

20

2975737M1

LUBRICATION NIPPLE

EnglischBem: NOTE: Pos. (20) included in Pos. (1) and (2) Kit

2шт.

21

3254083M1

PIN

EnglischBem: Ш 50,8 MM NOTE: Pos. (21) included in Pos. (1) and (2) Kit

2шт.

22

2975741M1

PIN

EnglischBem: NOTE: Pos. (22) included in Pos. (1) and (2) Kit

2шт.

23

2975740M1

PIN

EnglischBem: NOTE: Pos. (23) included in Pos. (1) and (2) Kit

2шт.

24

2975741M1

PIN

EnglischBem: NOTE: Pos. (24) included in Pos. (1) and (2) Kit

2шт.

25

2907094M1

BUSHING

EnglischBem: NOTE: Pos. (25) included in Pos. (1) and (2) Kit

4шт.

26

2907625M1

BUSHING

EnglischBem: NOTE: Pos. (26) included in Pos. (1) and (2) Kit

4шт.

27

2975742M1

TOOTH

DeutschDesc: ZAHN

9шт.

28

2975743M1

NUT

DeutschDesc: MUTTER

18шт.

29

2975744M1

SPRING WASHER

DeutschDesc: FEDERRING

18шт.

30

1891871M1

SCREW

DeutschDesc: SCHRAUBE

9шт.

31

2975746M1

SCREW

DeutschDesc: SCHRAUBE

9шт.

Выбрано товаров: 31
