Запчасти Komatsu L600D Super КОНДИЦ. ВОЗДУХА, СПЕЦ. ОБОРУД-Е КОНДИЦ. ВОЗДУХА, СПЕЦ. ОБОРУД-Е

1

4003472M91

AIR CONDITIONER

DeutschDesc: KLIMAANLAGE

1шт.

2

4003473M91

AIR CONDITIONER

EnglischBem: WITH FILTER

1шт.

3

4907100M91

HOOD

DeutschDesc: HAUBE

1шт.

4

4907101M91

HOOD

EnglischBem: WITH FILTER

1шт.

5

3236318M1

SCREW

EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (2) Kit

12шт.

6

3232403M1

AIR FILTER

EnglischBem: WITH FILTER

1шт.

7

4907105M91

COVER

EnglischBem: WITH FILTER

1шт.

8

4907102M91

BLOWER

EnglischBem: NOTE: Pos. (8) included in Pos. (1) and (2) Kit

1шт.

9

NOT USED

DeutschDesc: NICHT VERWENDET

-1шт.

10

4907106M91

ELECTRIC MOTOR

DeutschDesc: ELEKTROMOTOR

1шт.

11

NOT USED

DeutschDesc: NICHT VERWENDET

-1шт.

12

4907107M91

BLOWER

EnglischBem: NOTE: Pos. (12) included in Pos. (1) and (2) Kit

1шт.

13

NOT USED

DeutschDesc: NICHT VERWENDET

-1шт.

14

4907108M1

IMPELLER

DeutschDesc: FLUEGELRAD

1шт.

15

4907109M91

VALVE

EnglischBem: NOTE: Pos. (15) included in Pos. (1) and (2) Kit

1шт.

16

4907110M91

FILTER

EnglischBem: NOTE: Pos. (16) included in Pos. (1) and (2) Kit

1шт.

17

4907111M1

SWITCH

EnglischBem: LOW PRESSURE NOTE: Pos. (17) included in Pos. (1) and (2) Kit

1шт.

18

4907112M1

SWITCH

EnglischBem: HIGH PRESSURE NOTE: Pos. (18) included in Pos. (1) and (2) Kit

1шт.

19

4907113M1

RESISTOR

EnglischBem: NOTE: Pos. (19) included in Pos. (1) and (2) Kit

1шт.

20

3236248M91

RELAY

EnglischBem: NOTE: Pos. (20) included in Pos. (1) and (2) Kit

3шт.

21

3236247M91

SWITCH

EnglischBem: NOTE: Pos. (21) included in Pos. (1) and (2) Kit

1шт.

22

3236243M91

THERMOSTAT

EnglischBem: NOTE: Pos. (22) included in Pos. (1) and (2) Kit

1шт.

23

3236244M1

NUT

EnglischBem: NOTE: Pos. (23) included in Pos. (1) and (2) Kit

2шт.

24

4907103M1

BUTTON

EnglischBem: NOTE: Pos. (24) included in Pos. (1) and (2) Kit

1шт.

25

4907104M1

BUTTON

EnglischBem: NOTE: Pos. (25) included in Pos. (1) and (2) Kit

1шт.

26

4003481M91

DISTRIBUTOR

EnglischBem: NOTE: Pos. (26) included in Pos. (1) and (2) Kit

1шт.

27

1444206X1

SCREW

EnglischBem: NOTE: Pos. (27) included in Pos. (1) and (2) Kit

6шт.

28

1443791X1

SPRING WASHER

EnglischBem: NOTE: Pos. (28) included in Pos. (1) and (2) Kit

6шт.

29

3093121M1

NOZZLE

EnglischBem: NOTE: Pos. (29) included in Pos. (1) and (2) Kit

3шт.

30

3002033X1

PLOUGH BOLT

EnglischBem: NOTE: Pos. (30) included in Pos. (1) and (2) Kit

6шт.
