Запчасти Komatsu D87P-2 FIG. E-A КРЕПЛЕНИЯ АККУМУЛЯТОРАING ЭЛЕКТРИКА

|$0

1306 207 H91

MOUNTING, BATTERY

SN: Ser Num-UP

1шт.

1

1299 374 H92

PLATE, BATTERY MOUNTING

SN: Ser Num-UP

1шт.

|$2

24 859 R1

BOLT, HEX - 1/2NCx3/4

SN: Ser Num-UP

4шт.

|$3

25 536 R1

WASHER, FLAT - 1/2

SN: Ser Num-UP

5шт.

2

1299 373 H1

BAR, BATTERY MOUNTING

SN: Ser Num-UP

1шт.

|$5

1316 248 H1

BOLT, MOUNTING - 3/8NCx9 1/2

SN: Ser Num-UP

2шт.

|$6

25 544 R1

WASHER, FLAT - 3/8

SN: Ser Num-UP

2шт.

|$7

26 318 R1

BOLT, MOUNTING - 1/2NCx1 1/2

SN: Ser Num-UP

1шт.

3

476 074 C1

NUT, BATTERY TERMINAL - 3/8NC

SN: Ser Num-UP

4шт.

4

BATTERY (SEE FIG. E0110-02A0)

SN: Ser Num-UP

2шт.

|$10

-1шт.

|$11

F1 PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$12

-1шт.
