Запчасти Komatsu D87E-2 FIG. D-A ТОПЛ. БАК И ТОПЛИВОПРОВОД ТОПЛИВН. БАК. AND КОМПОНЕНТЫ

|$0

1315 562 H91

FUEL TANK AND FILTER PIPING

SN: P090001-UP

1шт.

1

07102-20329

HOSE, FUEL RETURN

SN: P090001-UP

1шт.

2

07102-20430

HOSE, FUEL SUPPLY

SN: P090001-UP

1шт.

3

299 615 C1

CLIP, FUEL RETURN HOSE

SN: P090001-UP

4шт.

4

299 413 C1

CLIP, FUEL SUPPLY HOSE

SN: P090001-UP

1шт.

|$6

OR

-1шт.

|$8

140-06-18440

CLIP, FUEL SUPPLY HOSE

SN: P090001-UP

1шт.

5

299 413 C1

CLIP, FUEL SUPPLY HOSE

SN: P090001-UP

3шт.

|$11

OR

-1шт.

|$13

140-06-18440

CLIP, FUEL SUPPLY HOSE

SN: P090001-UP

1шт.

|$14

24 839 R1

BOLT, HEX - 3/8x3/4

SN: P090001-UP

3шт.

|$15

670 278 C1

WASHER, FLAT - 3/8

SN: P090001-UP

3шт.

6

299 413 C1

CLIP, FUEL SUPPLY HOSE

SN: P090001-UP

1шт.

|$17

30 031 R1

BOLT, HEX - M10x80

SN: P090001-UP

1шт.

|$18

30 176 R1

WASHER, FLAT - M10

SN: P090001-UP

1шт.

|$19

468 460 R1

SPACER

SN: P090001-UP

1шт.

7

299 404 C1

CLIP, FUEL SPILL HOSE

SN: P090001-UP

4шт.

8

306 132 C2

STRAP, HOSE

SN: P090001-UP

4шт.

9

566-01-61190

ELBOW, 90°

SN: P090001-UP

1шт.

10

1301 358 H1

VALVE, FUEL SHUTOFF

SN: P090001-UP

1шт.

11

111 644

COUPLING

SN: P090001-UP

1шт.

12

1500 786 H1

ELBOW, 90°

SN: P090001-UP

1шт.

13

454 104

ELBOW

SN: P090001-UP

1шт.

14

628 703 C2

PIPE, DRAIN

SN: P090001-UP

1шт.

15

111 644

COUPLING

SN: P090001-UP

1шт.

16

148 344

VALVE, DRAIN

SN: P090001-UP

1шт.

17

HOSE, DRAIN - CUT TO FIT

SN: P090001-UP

1шт.

18

279 025 R91

CLAMP, HOSE

SN: P090001-UP

1шт.

|$33

OR

-1шт.

|$35

27 860 R1

CLAMP, HOSE

SN: P090001-UP

1шт.

19

628 704 C1

CLIP, DRAIN PIPE

SN: P090001-UP

1шт.

|$37

26 316 R1

BOLT, HEX - 1/2NCx1

SN: P090001-UP

1шт.

|$38

25 546 R1

WASHER, FLAT - 1/2

SN: P090001-UP

1шт.

20

TANK, FUEL (SEE FIG. D0100-01A0)

SN: P090001-UP

1шт.

21

433 182 C1

ELBOW, 90°

SN: P090001-UP

1шт.

22

105 409

COUPLING

SN: P090001-UP

1шт.

23

HOSE, FUEL SPILL - 4394 MM (173 IN)

SN: P090001-UP

1шт.

24

07280-01210

CLAMP

SN: P090001-UP

2шт.

|$44

-1шт.

|$45

F1 PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$46

-1шт.

|$47

-1шт.

|$48

F2 CUT FROM BULK HOSE 742 917 C1.

-1шт.

|$49

-1шт.

|$50

-1шт.

|$51

F3 CUT FROM BULK HOSE 427 698 C1.

-1шт.

|$52

-1шт.
