Запчасти Komatsu D87E-2 FIG. C-A SCAVENGING, СМАЗКА, ДРЕНАЖН. И ВЕНТИЛЯТОР ТРУБЫ СИСТЕМА ОХЛАЖДЕНИЯ

1

TORQUE CONVERTER (SEE FIG. F2310-01A0)

SN: P090001-UP

1шт.

2

296 247 R1

O-RING

SN: P090001-UP

1шт.

3

740 980 C1

TEE, OUTLET PORT

SN: P090001-UP

2шт.

4

SENSOR, CONVERTER OIL TEMP (SEE FIG. E0200-02A0)

SN: P090001-UP

1шт.

5

603 695 C91

HOSE, CONVERTER TO COOLER

SN: P090001-UP

1шт.

6

308 872 R1

CLIP, HOSE

SN: P090001-UP

2шт.

|$6

24 840 R1

BOLT, MOUNTING - 3/8NCx1

SN: P090001-UP

1шт.

|$7

25 544 R1

WASHER, FLAT - 3/8

SN: P090001-UP

1шт.

7

736 983 C1

HOSE

SN: P090001-UP

3шт.

8

306 132 C2

STRAP

SN: P090001-UP

6шт.

9

1101 584 C3

SWITCH, TEMPERATURE

SN: P090001-UP

1шт.

10

296 247 R1

O-RING

SN: P090001-UP

1шт.

11

RADIATOR (SEE FIG. C0100-02A0)

SN: P090001-UP

1шт.

12

9411 109

ELBOW

SN: P090001-UP

1шт.

13

1210 888 H1

HOSE

SN: P090001-UP

1шт.

14

ELBOW (SEE FIG. F2300-07A0)

SN: P090001-UP

1шт.

15

O-RING (SEE FIG. F2300-07A0)

SN: P090001-UP

1шт.

16

VALVE, PRESSURE REGULATOR (SEE FIG. F2300-07A0)

SN: P090001-UP

1шт.

17

308 872 R1

CLIP, HOSE

SN: P090001-UP

2шт.

|$19

24 839 R1

BOLT, HEX - 3/8NCx3/4

SN: P090001-UP

1шт.

|$20

25 544 R1

WASHER, FLAT - 3/8

SN: P090001-UP

1шт.

18

1500 721 H91

SUPPORT

SN: P090001-UP

1шт.

|$22

24 840 R1

BOLT, MOUNTING - 3/8NCx1

SN: P090001-UP

1шт.

|$23

25 544 R1

WASHER, FLAT - 3/8

SN: P090001-UP

1шт.
