Запчасти Komatsu D87E-2 FIG. C-A ВЕНТИЛЯТОР ДВИГ-ЛЯ КОЖУХ И ЧАСТИ КОРПУСАS СИСТЕМА ОХЛАЖДЕНИЯ

|$0

1315 553 H91

ENGINE FAN SHROUDS & GUARD

SN: P090001-UP

1шт.

1

1312 972 H91

SHROUD, FAN UPPER

SN: P090001-UP

1шт.

|$2

26 309 R1

BOLT, MOUNTING - 3/8NCx3/4

SN: P090001-UP

4шт.

|$3

25 534 R1

WASHER, FLAT - 3/8

SN: P090001-UP

4шт.

2

1312 974 H91

SHROUD, FAN LOWER

SN: P090001-UP

1шт.

|$5

26 309 R1

BOLT, MOUNTING - 3/8NCx3/4

SN: P090001-UP

4шт.

|$6

25 534 R1

WASHER, FLAT - 3/8

SN: P090001-UP

4шт.

3

1312 970 H1

LINER, SHROUD

SN: P090001-UP

2шт.

4

1312 971 H1

SUPPORT, SHROUD LINER

SN: P090001-UP

2шт.

|$9

27 768 R1

BOLT, MOUNTING - 3/8NCx7/8

SN: P090001-UP

10шт.

|$10

106 263 R1

WASHER, FLAT - 3/8

SN: P090001-UP

10шт.

5

1315 370 H1

GUARD, FAN RIGHT

SN: P090001-UP

1шт.

|$12

24 840 R1

BOLT, MOUNTING - 3/8NCx1

SN: P090001-UP

3шт.

|$13

24 847 R1

BOLT, MOUNTING - 3/8NCx5

SN: P090001-UP

2шт.

|$14

106 263 R1

WASHER, FLAT - 3/8

SN: P090001-UP

5шт.

6

1315 369 H1

GUARD, FAN LEFT

SN: P090001-UP

1шт.

|$16

24 840 R1

BOLT, MOUNTING - 3/8NCx1

SN: P090001-UP

3шт.

|$17

24 847 R1

BOLT, MOUNTING - 3/8NCx5

SN: P090001-UP

2шт.

|$18

106 263 R1

WASHER, FLAT - 3/8

SN: P090001-UP

5шт.

7

1315 371 H1

GUARD, FAN CENTER

SN: P090001-UP

1шт.

|$20

24 841 R1

BOLT, MOUNTING - 3/8NCx1 1/2

SN: P090001-UP

4шт.

|$21

106 263 R1

WASHER, FLAT - 3/8

SN: P090001-UP

4шт.

|$22

-1шт.

|$23

F1 PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$24

-1шт.

|$25

-1шт.

|$26

F2 FOR UNITS WITHOUT A/C.

-1шт.

|$27

-1шт.
