Запчасти Komatsu D87E-2 FIG. T8-A LANDFILL СЦЕПНОЕ УСТРОЙСТВО, ПРОТИВОВЕС, И ЗАДН. STRIKER BARS РАБОЧЕЕ ОБОРУДОВАНИЕ

1

1316 215 H91

BRACKET, COUNTERWEIGHT

SN: P090001-UP

1шт.

|$1

26 026 R1

BOLT, HEX - 1-1/4NCX3

SN: P090001-UP

12шт.

|$2

25 541 R1

WASHER - 1-1/4

SN: P090001-UP

12шт.

2

195-69-12121

WEIGHT

SN: P090001-UP

8шт.

3

1316 250 H1

STUD, MOUNTING

SN: P090001-UP

4шт.

4

25 984 R1

NUT, HEX - 1-1/4NC

SN: P090001-UP

8шт.

5

25 541 R1

WASHER - 1-1/4

SN: P090001-UP

8шт.

6

198-69-11291

PLATE, HOLDING

SN: P090001-UP

2шт.

7

1316 242 H91

DRAWBAR

SN: P090001-UP

1шт.

|$9

26 026 R1

BOLT, HEX - 1-1/4NCX3

SN: P090001-UP

12шт.

|$10

25 541 R1

WASHER - 1-1/4

SN: P090001-UP

12шт.

8

325 096 R1

PIN, DRAWBAR

SN: P090001-UP

1шт.

9

278 112 R1

CAM, CLEVIS PIN LOCK

SN: P090001-UP

1шт.

10

33 558 V

PIN, CLEVIS - 1/2X1-29/32

SN: P090001-UP

1шт.

11

103 384

PIN, COTTER - 1/8X3/4

SN: P090001-UP

1шт.

12

15A-69-A0020

STRIKER, RIGHT

SN: P090001-UP

1шт.

|$16

25 880 R1

BOLT, HEX - 1NCX3-3/4

SN: P090001-UP

4шт.

|$17

25 531 R1

NUT, HEX - 1NC

SN: P090001-UP

4шт.

|$18

25 553 R1

WASHER, HDN - 1

SN: P090001-UP

4шт.

13

15A-69-A0030

STRIKER, LEFT

SN: P090001-UP

1шт.

|$20

25 531 R1

NUT, HEX - 1NC

SN: P090001-UP

4шт.

|$21

25 553 R1

WASHER, HDN - 1

SN: P090001-UP

4шт.

|$22

25 880 R1

BOLT, HEX - 1NCX3-3/4

SN: P090001-UP

4шт.
