Запчасти Komatsu D87E-2 FIG. T-A РЫХЛИТЕЛЬ PITCH ЦИЛИНДР РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

1298 304 H91

CYLINDER ASSEMBLY, RIPPER PITCH

SN: P90001--UP

1шт.

|$1

1298 309 H91

HOUSING ASSY, CYLINDER

SN: P90001--UP

1шт.

1

NSS

HOUSING, CYLINDER

SN: P90001--UP

1шт.

2

707 080 C2

BUSHING, HOUSING

SN: P90001--UP

1шт.

3

20 513 R1

NUT, LOCK - 1-1/2NF

SN: P90001--UP

1шт.

4

26 609 R1

WASHER, FLAT - 1-1/2

SN: P90001--UP

1шт.

5

1298 312 H1

PISTON, CYLINDER

SN: P90001--UP

1шт.

6

1232 300 H1

GLAND, CYLINDER

SN: P90001--UP

1шт.

7

214 767 H2

RING, LOCK

SN: P90001--UP

1шт.

|$9

679 329 C92

KIT, SEAL

SN: P90001--UP

1шт.

8

NSS

O-RING

SN: P90001--UP

2шт.

9

NSS

RING, WEAR

SN: P90001--UP

2шт.

10

NSS

SEAL, PISTON

SN: P90001--UP

1шт.

11

NSS

RING, BACK-UP

SN: P90001--UP

1шт.

12

NSS

O-RING

SN: P90001--UP

1шт.

13

NSS

O-RING

SN: P90001--UP

1шт.

14

NSS

RING, WEAR

SN: P90001--UP

1шт.

15

NSS

RING, BUFFER

SN: P90001--UP

1шт.

16

NSS

O-RING

SN: P90001--UP

1шт.

17

NSS

SEAL, ROD

SN: P90001--UP

1шт.

18

NSS

WIPER, ROD

SN: P90001--UP

1шт.

19

741 183 C1

COVER

SN: P90001--UP

1шт.

|$22

26 311 R1

BOLT

SN: P90001--UP

6шт.

|$23

25 534 R1

WASHER

SN: P90001--UP

6шт.

|$24

706 753 C92

ROD ASSEMBLY, PISTON

SN: P90001--UP

1шт.

20

NSS

ROD, PISTON

SN: P90001--UP

1шт.

21

707 080 C2

BUSHING, ROD

SN: P90001--UP

1шт.

22

109 461

FITTING, LUBE

SN: P90001--UP

2шт.
