Запчасти Komatsu D87E-2 FIG. T-A РЫХЛИТЕЛЬ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

1500 921 H91

RIPPER ASSEMBLY

SN: P90001--UP

1шт.

|$1

635 355 C91

FRAME, MOUNTING

SN: P90001--UP

1шт.

1

710 292 C1

FRAME, MOUNTING

SN: P90001--UP

1шт.

2

710 280 C1

PIN, LIFT CYLINDER FRONT

SN: P90001--UP

2шт.

3

710 281 C1

PIN, CONNECTING LINK OR PITCH CYLINDER

SN: P90001--UP

2шт.

4

710 284 C1

PIN, DRAFT FRAME

SN: P90001--UP

2шт.

5

668 875 C1

PLATE, PIN RETAINER

SN: P90001--UP

8шт.

|$7

27 416 R1

BOLT

SN: P90001--UP

16шт.

|$8

25 538 R1

WASHER, FLAT

SN: P90001--UP

16шт.

|$9

26 026 R1

BOLT

SN: P90001--UP

14шт.

|$10

25 558 R1

WASHER, FLAT

SN: P90001--UP

14шт.

|$11

710 350 C92

LINK ASSEMBLY, CONNECTING

SN: P90001--UP

2шт.

6

109 461

FITTING, LUBRICATION

SN: P90001--UP

2шт.

7

707 080 C2

BUSHING, LINK

SN: P90001--UP

2шт.

8

NSS

LINK, CONNECTING

SN: P90001--UP

1шт.

9

CYLINDER, PITCH (SEE FIG. T2460-02A0)

SN: P90001--UP

2шт.

|$16

710 347 C92

FRAME ASSEMBLY, DRAFT

SN: P90001--UP

1шт.

10

109 461

FITTING, LUBRICATION

SN: P90001--UP

4шт.

11

710 348 C2

BUSHING, DRAFT FRAME

SN: P90001--UP

4шт.

12

NSS

FRAME, DRAFT

SN: P90001--UP

1шт.

13

668 875 C1

PLATE, PIN RETAINING

SN: P90001--UP

6шт.

|$21

27 416 R1

BOLT

SN: P90001--UP

12шт.

|$22

25 538 R1

WASHER, FLAT

SN: P90001--UP

12шт.

14

710 281 C1

PIN, CONNECTING LINK OR PITCH CYLINDER

SN: P90001--UP

2шт.

15

710 284 C1

PIN, DRAFT FRAME

SN: P90001--UP

2шт.

16

710 367 C1

PIN, LIFT CYLINDER REAR

SN: P90001--UP

2шт.

17

710 370 C1

BEAM, TOOL

SN: P90001--UP

1шт.

18

PIN, SHANK MOUNTING (SEE FIG. T2400-02A0)

SN: P90001--UP

3шт.

19

TUBE, LOCKING (SEE FIG. T2400-02A0)

SN: P90001--UP

6шт.

20

CYLINDER, LIFT (SEE FIG. T2460-01A0)

SN: P90001--UP

2шт.

|$30

-1шт.

|$31

F1 FOR MACHINES WITHOUT RIPPER PITCH.

-1шт.

|$32

-1шт.

|$33

-1шт.

|$34

F2 FOR MACHINES WITH RIPPER PITCH.

-1шт.

|$35

-1шт.
