Запчасти Komatsu D87E-2 FIG. T-A ПОВОРОТНЫЙ ОТВАЛ ОТВАЛ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

647 413 C91

BLADE, ANGLE DOZER

SN: P090001-UP

1шт.

1

317 490 R1

BAR, SWIVEL

SN: P090001-UP

4шт.

2

317 491 R1

PIN, SWIVEL BAR

SN: P090001-UP

4шт.

|$3

25 511 R1

BOLT, MOUNTING

SN: P090001-UP

4шт.

|$4

9412 231

NUT, LOCK

SN: P090001-UP

4шт.

3

319 041 R1

PIN, STRUT

SN: P090001-UP

4шт.

|$6

25 293 R1

BOLT, MOUNTING

SN: P090001-UP

4шт.

|$7

9412 230

NUT, LOCK

SN: P090001-UP

4шт.

4

600 670 C2

PIN, BLADE TO SWIVEL

SN: P090001-UP

1шт.

5

600 669 C1

PIN, MOUNTING

SN: P090001-UP

1шт.

|$10

137 185

PIN, COTTER

SN: P090001-UP

1шт.

6

NSS

BLADE, BULLGRADER

SN: P090001-UP

1шт.

7

646 258 C1

BLADE, CUTTING EDGE

SN: P090001-UP

2шт.

|$13

326 301 R1

BOLT, PLOW

SN: P090001-UP

24шт.

|$14

25 530 R1

NUT, MOUNTING

SN: P090001-UP

24шт.

8

646 261 C1

BIT, LEFT CUTTING EDGE END - STANDARD DUTY

SN: P090001-UP

1шт.

|$16

326 301 R1

BOLT, PLOW - 2-3/4 IN. LONG

SN: P090001-UP

4шт.

|$17

645 271 C1

BOLT, PLOW - 4 IN. LONG

SN: P090001-UP

3шт.

|$18

25 530 R1

NUT, MOUNTING

SN: P090001-UP

7шт.

9

646 262 C1

BIT, RIGHT CUTTING EDGE END - STANDARD DUTY

SN: P090001-UP

1шт.

|$20

326 301 R1

BOLT, PLOW - 2-3/4 IN. LONG

SN: P090001-UP

4шт.

|$21

645 271 C1

BOLT, PLOW - 4 IN. LONG

SN: P090001-UP

3шт.

|$22

25 530 R1

NUT, MOUNTING

SN: P090001-UP

7шт.

10

646 324 C1

PLATE, LEFT WEAR

SN: P090001-UP

1шт.

11

646 325 C1

PLATE, RIGHT WEAR

SN: P090001-UP

1шт.

12

705 639 C1

BRACKET, LEFT UPPER STRUT

SN: P090001-UP

1шт.

13

705 640 C1

BRACKET, RIGHT UPPER STRUT

SN: P090001-UP

1шт.

14

705 641 C1

BRACKET, LEFT LOWER STRUT

SN: P090001-UP

1шт.

15

705 642 C1

BRACKET, RIGHT LOWER STRUT

SN: P090001-UP

1шт.

|$29

-1шт.

|$30

F1 PART NUMBER IS A NON-SERVICE PART AND IS FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$31

-1шт.

|$32

-1шт.

|$33

F2 PART OF BLADE PIN PACKAGE 633 316 C91.

-1шт.

|$34

-1шт.
