Запчасти Komatsu D87E-2 FIG. T-A BULLDOZER ОТВАЛ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

1500 356 H91

BLADE ASSEMBLY

SN: P90001--UP

1шт.

1

NSS

BLADE, BULLDOZER

SN: P90001--UP

1шт.

2

734 887 C2

SOCKET, UPPER STRUT OR TILT CYLINDER

SN: P90001--UP

2шт.

3

737 860 C2

BRACKET, LIFT CYLINDER

SN: P90001--UP

2шт.

4

628 837 C1

LOOP, STRUT LOCK

SN: P90001--UP

2шт.

5

1500 389 H91

BRACKET, LEFT PUSH ARM

SN: P90001--UP

1шт.

6

1500 388 H91

BRACKET, RIGHT PUSH ARM

SN: P90001--UP

1шт.

7

738 664 C1

SOCKET, DIAGONAL STRUT

SN: P90001--UP

2шт.

8

1500 374 H1

PLATE, SIDE CUTTER

SN: P90001--UP

2шт.

9

NSS

PLATE, LOWER WEAR

SN: P90001--UP

2шт.

10

317 386 R1

SHIM, DIAGONAL STRUT

SN: P90001--UP

-2шт.

|$11

26 019 R1

BOLT, MOUNTING

SN: P90001--UP

8шт.

|$12

25 540 R1

WASHER, FLAT

SN: P90001--UP

8шт.

11

109 461

FITTING, LUBRICATION

SN: P90001--UP

2шт.

12

317 497 R1

PIN, LIFT CYLINDER

SN: P90001--UP

2шт.

|$15

25 285 R1

BOLT, MOUNTING

SN: P90001--UP

2шт.

|$16

9412 230

NUT, LOCK

SN: P90001--UP

2шт.

13

734 899 C2

PIN, PUSH ARM

SN: P90001--UP

2шт.

14

710 488 C1

PLATE, PUSH ARM PIN RETAINER

SN: P90001--UP

2шт.

|$19

24 874 R1

BOLT, MOUNTING

SN: P90001--UP

8шт.

15

317 386 R1

SHIM, UPPER STRUT OR TILT CYLINDER

SN: P90001--UP

8шт.

|$21

26 019 R1

BOLT, MOUNTING

SN: P90001--UP

8шт.

|$22

25 540 R1

WASHER, FLAT

SN: P90001--UP

8шт.

16

109 461

FITTING, LUBRICATION

SN: P90001--UP

2шт.

17

734 528 C1

BLADE, CENTER CUTTING EDGE

SN: P90001--UP

1шт.

|$25

326 301 R1

BOLT, PLOW

SN: P90001--UP

7шт.

|$26

25 530 R1

NUT, MOUNTING

SN: P90001--UP

7шт.

18

734 529 C1

BLADE, CUTTING EDGE

SN: P90001--UP

2шт.

|$28

326 301 R1

BOLT, PLOW

SN: P90001--UP

10шт.

|$29

25 530 R1

NUT, MOUNTING

SN: P90001--UP

10шт.

19

734 532 C1

BIT, LEFT CUTTING EDGE END

SN: P90001--UP

1шт.

|$31

326 301 R1

BOLT, PLOW

SN: P90001--UP

7шт.

|$32

25 530 R1

NUT, MOUNTING

SN: P90001--UP

7шт.

20

734 531 C1

BIT, RIGHT CUTTING EDGE END

SN: P90001--UP

1шт.

|$34

326 301 R1

BOLT, PLOW

SN: P90001--UP

7шт.

|$35

25 530 R1

NUT, MOUNTING

SN: P90001--UP

7шт.

|$36

-1шт.

|$37

F1 PART NUMBER IS A NO-SERVICE PART AND IS FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$38

-1шт.

|$39

-1шт.

|$40

F2 PART OF BLADE PIN PACKAGE 633 317 C91.

-1шт.

|$41

-1шт.
