Запчасти Komatsu D87E-2 FIG. T-A ПОВОРОТНЫЙ ОТВАЛ ОБОРУД-Е РАБОЧЕЕ ОБОРУДОВАНИЕ

1

BLADE, ANGLE DOZER (SEE FIG. T2120-02A0)

SN: P90001--UP

1шт.

2

CYLINDER, BLADE TILT (SEE FIG. T2150-01A0)

SN: P90001--UP

2шт.

3

STRUT, LOWER LEFT (SEE FIG. T2115-02A0)

SN: P90001--UP

1шт.

4

STRUT, LOWER RIGHT (SEE FIG. T2115-03A0)

SN: P90001--UP

1шт.

5

FRAME, C (SEE FIG. T2110-04A0)

SN: P90001--UP

1шт.

6

628 843 C2

TRUNNION ASSEMBLY, C FRAME - LEFT

SN: P90001--UP

1шт.

7

628 845 C2

BALL, TRUNNION

SN: P90001--UP

1шт.

|$7

25 894 R1

BOLT, MOUNTING

SN: P90001--UP

8шт.

|$8

25 540 R1

WASHER, FLAT

SN: P90001--UP

8шт.

8

628 844 C2

TRUNNION ASSEMBLY, C FRAME - RIGHT

SN: P90001--UP

1шт.

9

628 845 C2

BALL, TRUNNION

SN: P90001--UP

1шт.

|$11

25 894 R1

BOLT, MOUNTING

SN: P90001--UP

8шт.

|$12

25 540 R1

WASHER, FLAT

SN: P90001--UP

8шт.
