Запчасти Komatsu D87E-2 FIG. T-A ПОВОРОТНЫЙ ОТВАЛ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

1299 297 H92

FRAME ASSEMBLY,

SN: P90001--UP

1шт.

1

NSS

FRAME, C

SN: P90001--UP

1шт.

2

620 914 C2

BUSHING, SWIVEL PIN - LARGE

SN: P90001--UP

1шт.

3

317 499 R1

BUSHING, SWIVEL PIN - SMALL

SN: P90001--UP

1шт.

4

646 520 C1

BLOCK, TRUNNION

SN: P90001--UP

2шт.

5

1299 299 H91

BRACKET, LIFT CYLINDER LEFT

SN: P90001--UP

1шт.

6

1299 900 H91

BRACKET, LIFT CYLINDER RIGHT

SN: P90001--UP

1шт.

7

645 704 C2

BRACKET, STRUT FRONT LEFT

SN: P90001--UP

1шт.

8

645 705 C2

BRACKET, STRUT FRONT RIGHT

SN: P90001--UP

1шт.

9

645 706 C2

BRACKET, STRUT MIDDLE AND REAR

SN: P90001--UP

4шт.

10

620 913 C1

PIN, BLADE SWIVEL

SN: P90001--UP

1шт.

11

319 111 R1

PLATE, PIN RETAINING

SN: P90001--UP

1шт.

12

1299 503 H1

STEP

SN: P90001--UP

2шт.

13

717 740 C1

CAP, TRUNNION

SN: P90001--UP

2шт.

|$14

26 015 R1

BOLT, MOUNTING

SN: P90001--UP

4шт.

|$15

25 540 R1

WASHER, FLAT

SN: P90001--UP

4шт.

|$16

290 256 R2

NUT, MOUNTING

SN: P90001--UP

4шт.

14

290 257 R1

SHIM, TRUNNION CAP

SN: P90001--UP

-2шт.

15

317 497 R1

PIN, LIFT CYLINDER

SN: P90001--UP

2шт.

|$19

25 285 R1

BOLT, MOUNTING

SN: P90001--UP

2шт.

|$20

9412 230

NUT, LOCK

SN: P90001--UP

2шт.
