Запчасти Komatsu D87E-2 FIG. T-A ЛЕВ. PUSH РУКОЯТЬ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

1500 883 H91

ARM ASSEMBLY, LEFT PUSH

SN: P090001-UP

1шт.

1

1500 884 H91

ARM ASSEMBLY, LEFT PUSH

SN: P090001-UP

1шт.

2

NSS

ARM, PUSH

SN: P090001-UP

1шт.

3

628 864 C1

BLOCK, TRUNNION

SN: P090001-UP

1шт.

4

734 894 C1

BRACKET, UPPER STRUT OR TILT CYLINDER

SN: P090001-UP

1шт.

5

734 897 C1

BRACKET, DIAGONAL STRUT

SN: P090001-UP

1шт.

6

1214 358 H91

PIVOT ASSEMBLY, BLADE

SN: P090001-UP

1шт.

7

734 821 C1

BUSHING, PIVOT

SN: P090001-UP

1шт.

8

734 904 C1

PIN, STRUT MOUNTING

SN: P090001-UP

2шт.

9

734 905 C1

PLATE, PIN RETAINER

SN: P090001-UP

2шт.

|$10

24 861 R1

BOLT, MOUNTING

SN: P090001-UP

4шт.

10

717 740 C1

CAP, TRUNNION

SN: P090001-UP

1шт.

|$12

26 015 R1

BOLT, MOUNTING

SN: P090001-UP

2шт.

|$13

25 540 R1

WASHER, FLAT

SN: P090001-UP

2шт.

|$14

290 256 R2

NUT, MOUNTING

SN: P090001-UP

2шт.

11

290 257 R1

SHIM, TRUNNION CAP

SN: P090001-UP

-2шт.

12

1284 516 H1

STEP

SN: P090001-UP

1шт.

13

1500 359 H1

STEP

SN: P090001-UP

1шт.

14

1500 360 H1

BAR

SN: P090001-UP

2шт.

|$19

-1шт.

|$20

F1 PART NUMBER IS A NON-SERVICE PART AND IS FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$21

-1шт.
