Запчасти Komatsu D87E-2 FIG. T-A BULLDOZER ОБОРУД-Е РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

1500 459 H91

BLADE EQUIPMENT

SN: P90001--UP

1шт.

1

BLADE (SEE FIG. T2120-01A0)

SN: P90001--UP

1шт.

2

STRUT, DIAGONAL (SEE FIG. T2110-05A0)

SN: P90001--UP

2шт.

3

STRUT, LEFT UPPER (SEE FIG. T2110-06A0)

SN: P90001--UP

1шт.

4

STRUT, RIGHT UPPER (SEE FIG. T2110-06A0)

SN: P90001--UP

1шт.

|$6

OR

-1шт.

|$8

CYLINDER, BLADE TILT (SEE FIG. T2152-01A0)

SN: P90001--UP

1шт.

5

PIN, MOUNTING (SEE FIG. T2110-02A0)

SN: P90001--UP

4шт.

|$11

OR

-1шт.

|$13

PIN, MOUNTING (SEE FIG. T2110-03A0)

SN: P90001--UP

4шт.

6

ARM, LEFT PUSH (SEE FIG. T2110-03A0)

SN: P90001--UP

1шт.

7

ARM, RIGHT PUSH (SEE FIG. T2110-02A0)

SN: P90001--UP

1шт.

8

628 843 C2

TRUNNION, PUSH ARM - LEFT

SN: P90001--UP

1шт.

9

628 845 C2

BALL, TRUNNION

SN: P90001--UP

1шт.

|$18

25 894 R1

BOLT, MOUNTING

SN: P90001--UP

8шт.

|$19

25 540 R1

WASHER, FLAT

SN: P90001--UP

8шт.

10

628 844 C2

TRUNNION, PUSH ARM - RIGHT

SN: P90001--UP

1шт.

11

628 845 C2

BALL, TRUNNION

SN: P90001--UP

1шт.

|$22

25 894 R1

BOLT, MOUNTING

SN: P90001--UP

8шт.

|$23

25 540 R1

WASHER, FLAT

SN: P90001--UP

8шт.

|$24

-1шт.

|$25

F1 PART NUMBER IS A NON-SERVICE PART AND IS FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$26

-1шт.
