Запчасти Komatsu D87E-2 FIG. R-A ГУСЕНИЧНАЯ РАМА ХОДОВАЯ

|$0

1252 667 H91

FRAME ASSEMBLY, RIGHT TRACK

SN: P090001-UP

1шт.

1

740 368 C1

BUSHING, OUTER PIVOT SHAFT

SN: P090001-UP

1шт.

2

740 369 C1

BUSHING, INNER PIVOT SHAFT

SN: P090001-UP

1шт.

3

1251 882 H1

BAR, FRONT LOWER GUIDE WEAR

SN: P090001-UP

2шт.

4

1250 714 H1

BAR, CHAIN GUIDE WEAR

SN: P090001-UP

2шт.

5

NSS

FRAME, TRACK

SN: P090001-UP

1шт.

6

1250 176 H91

DOOR, ADJUSTER ACCESS

SN: P090001-UP

1шт.

|$7

26 317 R1

BOLT, MOUNTING - 1/2NCx1-1/4

SN: P090001-UP

1шт.

|$8

25 555 R1

WASHER, FLAT - 1/2

SN: P090001-UP

1шт.

7

21 510 R1

SPACER, PIPE - 3/8x1/2

SN: P090001-UP

2шт.

8

Q 671

PIN, HEADED - 3/8x5-3/4

SN: P090001-UP

1шт.

9

9409 949

PLUG, PIPE

SN: P090001-UP

1шт.

|$12

1252 666 H91

FRAME ASSEMBLY, LEFT TRACK

SN: P090001-UP

1шт.

1

740 368 C1

BUSHING, OUTER PIVOT SHAFT

SN: P090001-UP

1шт.

2

740 369 C1

BUSHING, INNER PIVOT SHAFT

SN: P090001-UP

1шт.

3

1251 882 H1

BAR, FRONT LOWER GUIDE WEAR

SN: P090001-UP

2шт.

4

1250 714 H1

BAR, CHAIN GUIDE WEAR

SN: P090001-UP

2шт.

5

NSS

FRAME, TRACK

SN: P090001-UP

1шт.

6

1250 176 H91

DOOR, ADJUSTER ACCESS

SN: P090001-UP

1шт.

|$19

26 317 R1

BOLT, MOUNTING - 1/2NCx1-1/4

SN: P090001-UP

1шт.

|$20

25 555 R1

WASHER, FLAT - 1/2

SN: P090001-UP

1шт.

7

21 510 R1

SPACER, PIPE - 3/8x1/2

SN: P090001-UP

2шт.

8

Q 671

PIN, HEADED - 3/8x5-3/4

SN: P090001-UP

1шт.

9

9409 949

PLUG, PIPE

SN: P090001-UP

1шт.
