Запчасти Komatsu D87E-2 FIG. R-A ГУСЕНИЧНАЯ РАМА КРЕПЛЕНИЕ ХОДОВАЯ

1

655 337 C4

SHAFT, PIVOT

SN: P90001--UP

2шт.

2

316 751 R1

PIN, PIVOT SHAFT LOCK

SN: P90001--UP

2шт.

3

1284 561 H1

RETAINER, LOCK PIN

SN: P90001--UP

2шт.

4

715 622 C1

SEAL, PIVOT SHAFT

SN: P90001--UP

2шт.

5

635 407 C2

PLATE, PIVOT SHAFT RETAINER

SN: P90001--UP

2шт.

|$5

25 963 R1

BOLT, MOUNTING

SN: P90001--UP

6шт.

|$6

39 422 D

WASHER

SN: P90001--UP

8шт.

6

655 422 C1

SHIM, RETAINER PLATE - 0.120 IN.

SN: P90001--UP

-2шт.

|$8

655 423 C1

SHIM, RETAINER PLATE - 0.030 IN.

SN: P90001--UP

-2шт.

7

334 428 R2

WASHER, WEAR

SN: P90001--UP

4шт.

8

707 586 C1

COVER, PIVOT SHAFT

SN: P90001--UP

2шт.

|$11

24 890 R1

BOLT, MOUNTING

SN: P90001--UP

8шт.

|$12

39 422 D

WASHER, FLAT

SN: P90001--UP

8шт.

|$13

655 415 C92

BAR ASSEMBLY, EQUALIZER

SN: P90001--UP

1шт.

9

NSS

BAR, EQUALIZER

SN: P90001--UP

1шт.

10

655 417 C1

BUSHING, EQUALIZER BAR

SN: P90001--UP

2шт.

11

662 561 C1

PAD, EQUALIZER BAR WEAR

SN: P90001--UP

2шт.

12

655 419 C1

PIN, EQUALIZER BAR PIVOT

SN: P90001--UP

1шт.

13

603 282 C1

PLATE, RETAINER

SN: P90001--UP

2шт.

|$19

25 509 R1

BOLT, MOUNTING

SN: P90001--UP

8шт.

|$20

25 537 R1

WASHER, FLAT

SN: P90001--UP

8шт.

14

1251 778 H91

BAR, EQUALIZER BAR REBOUND

SN: P90001--UP

2шт.

|$22

24 890 R1

BOLT, MOUNTING

SN: P90001--UP

8шт.

|$23

25 538 R1

WASHER, FLAT

SN: P90001--UP

8шт.

15

1252 242 H1

WASHER, REBOUND BAR SHIM

SN: P90001--UP

-2шт.

16

ROLLER, DOUBLE FLANGE TRACK (SEE FIG. R2100-04A0)

SN: P90001--UP

8шт.

|$26

24 890 R1

BOLT, MOUNTING

SN: P90001--UP

32шт.

|$27

25 538 R1

WASHER, FLAT

SN: P90001--UP

32шт.

17

ROLLER, SINGLE FLANGE TRACK (SEE FIG. R2100-03A0)

SN: P90001--UP

6шт.

|$29

24 890 R1

BOLT, MOUNTING

SN: P90001--UP

24шт.

|$30

25 538 R1

WASHER, FLAT

SN: P90001--UP

24шт.

18

IDLER, TRACK TOP (SEE FIG. R2100-05A0)

SN: P90001--UP

4шт.

19

636 883 C1

BRACKET, REAR TOP IDLER MOUNTING

SN: P90001--UP

2шт.

|$33

25 911 R1

BOLT, MOUNTING

SN: P90001--UP

8шт.

|$34

25 539 R1

WASHER, FLAT

SN: P90001--UP

8шт.

20

636 882 C1

BRACKET, FRONT TOP IDLER MOUNTING

SN: P90001--UP

2шт.

|$36

25 911 R1

BOLT, MOUNTING

SN: P90001--UP

8шт.

|$37

25 539 R1

WASHER, FLAT

SN: P90001--UP

8шт.

21

662 663 C1

SEAT, TRACK SPRING FRONT

SN: P90001--UP

2шт.

22

662 664 C1

SEAT, TRACK SPRING REAR

SN: P90001--UP

2шт.

23

662 662 C1

SPRING, TRACK

SN: P90001--UP

4шт.

|$41

1252 707 H91

TRACK FRAMES AND GUIDE SYSTEM

SN: P90001--UP

1шт.

24

655 409 C2

PLATE, GUIDE WEAR

SN: P90001--UP

4шт.

25

655 465 C1

BAR, GUIDE PLATE SPACER - UPPER

SN: P90001--UP

2шт.

26

740 169 C1

BAR, GUIDE PLATE SPACER - LOWER

SN: P90001--UP

2шт.

27

655 466 C2

SHIM, SPACER BAR - 0.060 IN.

SN: P90001--UP

-2шт.

|$46

740 530 C1

SHIM, SPACER BAR - 0.030 IN.

SN: P90001--UP

-2шт.

28

655 404 C1

PLATE, GUIDE

SN: P90001--UP

2шт.

|$48

25 880 R1

BOLT, MOUNTING

SN: P90001--UP

8шт.

|$49

25 540 R1

WASHER, FLAT

SN: P90001--UP

8шт.

29

739 484 C1

PLATE, TRACK FRAME RETAINER

SN: P90001--UP

2шт.

|$51

26 720 R1

BOLT, MOUNTING

SN: P90001--UP

8шт.

|$52

25 540 R1

WASHER, FLAT

SN: P90001--UP

8шт.

30

655 405 C2

SHIM, GUIDE PLATE - 0.060 IN.

SN: P90001--UP

-2шт.

|$54

740 529 C1

SHIM, GUIDE PLATE - 0.030 IN.

SN: P90001--UP

-2шт.

31

FRAME, LEFT TRACK (SEE FIG. R2100-02A0)

SN: P90001--UP

1шт.

|$56

FRAME, RIGHT TRACK(SEE FIG. R2100-02A0)

SN: P90001--UP

1шт.

|$57

25 277 R1

BOLT, MOUNTING - 1/2NFX1-3/4

SN: P90001--UP

2шт.

|$58

616 192 C1

NUT, SQUARE

SN: P90001--UP

2шт.

|$59

OR

SN: P90001--UP

-1шт.

|$60

1284 866 H1

NUT, SQUARE

SN: P90001--UP

2шт.

32

1251 887 H1

SHIELD, FRONT IDLER

SN: P90001--UP

4шт.

|$62

24 873 R1

BOLT, MOUNTING - 5/8NCX1-1/2

SN: P90001--UP

8шт.

|$63

25 537 R1

WASHER, FLAT - 5/8

SN: P90001--UP

8шт.

33

IDLER, TRACK FRONT (SEE FIG. R2100-07A0)

SN: P90001--UP

2шт.

34

CYLINDER W/FORK, TRACK ADJUSTER (SEE FIG. R2100-06A0)

SN: P90001--UP

2шт.

|$66

1251 945 H91

DEFLECTOR, SPROCKET ROCK

SN: P90001--UP

1шт.

35

1251 884 H91

DEFLECTOR, LEFT SPROCKET ROCK

SN: P90001--UP

2шт.

|$68

24 888 R1

BOLT

SN: P90001--UP

16шт.

|$69

25 548 R1

WASHER

SN: P90001--UP

16шт.

36

1251 885 H91

DEFLECTOR, RIGHT SPROCKET ROCK

SN: P90001--UP

2шт.

|$71

24 888 R1

BOLT

SN: P90001--UP

16шт.

|$72

25 548 R1

WASHER

SN: P90001--UP

16шт.

|$73

703 702 C91

TRACK ROLLER SHIELD

SN: P90001--UP

1шт.

37

739 465 C1

SHIELD, RIGHT TRACK ROLLER

SN: P90001--UP

2шт.

|$75

24 887 R1

BOLT

SN: P90001--UP

14шт.

|$76

25 548 R1

WASHER

SN: P90001--UP

14шт.

38

739 464 C1

SHIELD, LEFT TRACK ROLLER

SN: P90001--UP

2шт.

|$78

24 887 R1

BOLT

SN: P90001--UP

14шт.

|$79

25 548 R1

WASHER

SN: P90001--UP

14шт.

39

662 642 C1

TUBE, SPACER

SN: P90001--UP

12шт.

|$81

26 598 R1

BOLT

SN: P90001--UP

14шт.

|$82

25 548 R1

WASHER

SN: P90001--UP

28шт.

|$83

25 529 R1

NUT

SN: P90001--UP

14шт.

|$84

703 701 C91

TRACK ROLLER SHIELD - CENTER

SN: P90001--UP

1шт.

40

739 461 C1

GUIDE, TRACK CHAIN

SN: P90001--UP

4шт.

|$86

24 887 R1

BOLT

SN: P90001--UP

8шт.

|$87

26 598 R1

BOLT

SN: P90001--UP

8шт.

|$88

25 548 R1

WASHER

SN: P90001--UP

16шт.

|$89

9413 983

NUT

SN: P90001--UP

4шт.

41

662 642 C1

TUBE, SPACER

SN: P90001--UP

4шт.

42

1251 883 H91

BAR, FRONT IDLER WEAR

SN: P90001--UP

4шт.

|$92

19 838 R1

PIN, DOWEL

SN: P90001--UP

2шт.

|$93

24 873 R1

BOLT

SN: P90001--UP

8шт.

|$94

25 537 R1

WASHER

SN: P90001--UP

8шт.

43

BAR, FRONT LOWER GUIDE WEAR (SEE FIG. R2100-02A0

SN: P90001--UP

2шт.

|$96

-1шт.

|$97

F1 PART NUMBER IS A NON-SERVICE PART AND IS FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$98

-1шт.
