Запчасти Komatsu D87E-2 FIG. M7-A ПЕРЕДН. И ЗАДН. SWEEPS ЧАСТИ КОРПУСА

|$0

1315 628 H91

SWEEPS, FRONT AND REAR

SN: P090001-UP

1шт.

1

ROPS (SEE FIG. K0410-02A0)

SN: P090001-UP

1шт.

2

1311 953 H1

BLOCK

SN: P090001-UP

2шт.

3

1311 902 H91

SUPPORT, REAR SWEEP

SN: P090001-UP

1шт.

|$4

25 996 R1

BOLT, 1NCx6

SN: P090001-UP

2шт.

|$5

25 550 R1

WASHER, 1 HDN

SN: P090001-UP

2шт.

4

1311 907 H91

BOW, LEFT REAR

SN: P090001-UP

1шт.

|$7

26 011 R1

BOLT, 1NCx6

SN: P090001-UP

2шт.

|$8

9413 986

NUT, PREV TQ - 1NC

SN: P090001-UP

2шт.

|$9

25 550 R1

WASHER, 1 HDN

SN: P090001-UP

2шт.

5

1311 906 H91

BOW, RIGHT REAR

SN: P090001-UP

1шт.

|$11

26 011 R1

BOLT, 1NCx6

SN: P090001-UP

2шт.

|$12

9413 986

NUT, PREV TQ - 1NC

SN: P090001-UP

2шт.

|$13

25 550 R1

WASHER, 1 HDN

SN: P090001-UP

2шт.

6

652 757 C1

BUSHING

SN: P090001-UP

4шт.

|$15

26 632 R1

BOLT, 1NCx6-1/2

SN: P090001-UP

4шт.

|$16

9413 986

NUT, PREV TQ - 1NC

SN: P090001-UP

4шт.

|$17

25 550 R1

WASHER, 1 HDN

SN: P090001-UP

4шт.

7

1311 901 H91

SUPPORT, REAR SWEEPS

SN: P090001-UP

1шт.

|$19

149 864 H1

BOSS- RND, 5/8NCx1x1-1/2

SN: P090001-UP

4шт.

|$20

24 873 R1

BOLT, HEX - 5/8NCx1-1/2

SN: P090001-UP

4шт.

|$21

25 556 R1

WASHER, HDN - 5/8

SN: P090001-UP

4шт.

|$22

25 537 R1

WASHER, HDN - 5/8

SN: P090001-UP

16шт.

8

1311 910 H1

PLATE, SPACER

SN: P090001-UP

2шт.

9

1315 776 H91

BOW, LEFT FRONT

SN: P090001-UP

1шт.

10

1315 771 H91

BOW, RIGHT FRONT

SN: P090001-UP

1шт.

11

1311 905 H91

SUPPORT, FRONT SWEEP

SN: P090001-UP

1шт.

|$27

25 996 R1

BOLT, 1NCx6

SN: P090001-UP

2шт.

|$28

25 550 R1

WASHER, 1 HDN

SN: P090001-UP

2шт.

12

1315 775 H1

CROSS BEAM, SWEEP

SN: P090001-UP

1шт.

|$30

24 889 R1

BOLT, 3/4NCx2-1/4

SN: P090001-UP

2шт.

|$31

25 529 R1

NUT, 3/4NC

SN: P090001-UP

2шт.

|$32

25 538 R1

WASHER, HDN 3/4

SN: P090001-UP

4шт.

13

1315 769 H91

MOUNT, FRT. SWEEP

SN: P090001-UP

2шт.

14

1315 779 H1

BLOCK SUPPORT, LEFT

SN: P090001-UP

1шт.

15

1315 778 H1

BLOCK SUPPORT, RIGHT

SN: P090001-UP

1шт.

16

1311 908 H91

PLATE, ROOF CANOPY

SN: P090001-UP

1шт.

|$37

24 872 R1

BOLT, 5/8NCx1-1/4

SN: P090001-UP

14шт.

|$38

25 537 R1

WASHER, 5/8 HDN

SN: P090001-UP

14шт.

|$39

1311 912 H91

SCREEN, REAR CANOPY

SN: P090001-UP

1шт.

17

1311 913 H91

SCREEN, REAR

SN: P090001-UP

1шт.

|$41

24 873 R1

BOLT, MTG - 5/8NCx1-1/2

SN: P090001-UP

4шт.

|$42

25 346 R1

BOLT, HEX - 5/8NCx5-1/2

SN: P090001-UP

8шт.

|$43

25 547 R1

WASHER, HDN - 5/8

SN: P090001-UP

20шт.

|$44

25 528 R1

NUT, HEX - 5/8NC

SN: P090001-UP

8шт.
