Запчасти Komatsu D87E-2 FIG. M-A БАК ЧАСТИ КОРПУСАING - LANDFILL PACKAGE ЧАСТИ КОРПУСА

1

1316 200 H1

BAR, DOOR LOCK

SN: P090001-UP

2шт.

2

149 864 H1

BOSS, 5/8X1-1/2

SN: P090001-UP

20шт.

3

1316 099 H91

COVER, LEFT

SN: P090001-UP

1шт.

|$3

24 873 R1

BOLT, HEX - 5/8NCX1-1/2

SN: P090001-UP

6шт.

|$4

25 547 R1

WASHER - 5/8

SN: P090001-UP

6шт.

4

1316 098 H91

COVER, RIGHT

SN: P090001-UP

1шт.

|$6

24 873 R1

BOLT, HEX - 5/8NCX1-1/2

SN: P090001-UP

6шт.

|$7

25 547 R1

WASHER - 5/8

SN: P090001-UP

6шт.

5

1316 095 H91

COVER, REAR

SN: P090001-UP

1шт.

|$9

24 873 R1

BOLT, HEX - 5/8NCX1-1/2

SN: P090001-UP

6шт.

|$10

25 547 R1

WASHER - 5/8

SN: P090001-UP

6шт.

6

1316 092 H1

CORNER, LEFT

SN: P090001-UP

1шт.

|$12

24 873 R1

BOLT, HEX - 5/8NCX1-1/2

SN: P090001-UP

6шт.

|$13

25 547 R1

WASHER - 5/8

SN: P090001-UP

6шт.

7

1316 093 H1

CORNER, RIGHT

SN: P090001-UP

1шт.

|$15

24 873 R1

BOLT, HEX - 5/8NCX1-1/2

SN: P090001-UP

6шт.

|$16

25 547 R1

WASHER - 5/8

SN: P090001-UP

6шт.

8

1316 221 H91

DOOR, TANK GUARD

SN: P090001-UP

2шт.

9

17A-54-A0825

EYE, DOOR LOCKING

SN: P090001-UP

4шт.

10

6202-43-5340

SPRING

SN: P090001-UP

4шт.

11

25 546 R1

WASHER - 1/2

SN: P090001-UP

4шт.

12

103 385

PIN, COTTER - 1/8X1

SN: P090001-UP

4шт.

13

365 704 R1

PIN, SPRING - 1/8X5/8

SN: P090001-UP

4шт.

14

4610 271 H1

PIN, HINGE

SN: P090001-UP

4шт.

15

1316 091 H1

BAR, SPACER

SN: P090001-UP

2шт.
