Запчасти Komatsu D87E-2 FIG. M-A ЦИЛИНДР ПОДЪЕМА ОТВАЛА КРЕПЛЕНИЕ ЧАСТИ КОРПУСА

|$0

1500 954 H91

BLADE LIFT CYLINDER MOUNTING

SN: P90001--UP

1шт.

1

1500 950 H91

TUBE

SN: P90001--UP

1шт.

|$2

25 848 R1

BOLT

SN: P90001--UP

6шт.

|$3

25 862 R1

WASHER

SN: P90001--UP

6шт.

2

734 936 C1

PLUG

SN: P90001--UP

2шт.

3

734 944 C1

BUSHING

SN: P90001--UP

2шт.

4

734 943 C1

BUSHING

SN: P90001--UP

2шт.

5

110 891 H

BREATHER

SN: P90001--UP

2шт.

6

742 151 C1

RETAINER

SN: P90001--UP

2шт.

7

28 108 R1

O-RING

SN: P90001--UP

2шт.

8

444 614

PLUG

SN: P90001--UP

2шт.

9

1212 409 H1

COVER

SN: P90001--UP

2шт.

|$12

24 862 R1

BOLT

SN: P90001--UP

4шт.

|$13

25 546 R1

WASHER

SN: P90001--UP

4шт.

10

933 209 C1

SEAL

SN: P90001--UP

2шт.

|$15

734 896 C91

YOKE, LIFT

SN: P90001--UP

1шт.

11

NSS

YOKE

SN: P90001--UP

1шт.

|$17

1233 021 H91

PACKAGE, SERVICE CAP

SN: P90001--UP

1шт.

12

734 940 C1

BUSHING

SN: P90001--UP

2шт.

13

1233 022 H1

CAP

SN: P90001--UP

2шт.

|$20

24 893 R1

BOLT

SN: P90001--UP

4шт.

|$21

25 538 R1

WASHER

SN: P90001--UP

4шт.

14

19 955 R1

PIN

SN: P90001--UP

2шт.

15

109 461

FITTING

SN: P90001--UP

2шт.

16

717 501 C1

SHIM (.010)

SN: P90001--UP

6шт.

|$25

717 502 C1

SHIM (.007)

SN: P90001--UP

4шт.

|$26

717 503 C1

SHIM (.005)

SN: P90001--UP

6шт.

17

CYLINDER (SEE FIG. T2140-01A0)

SN: P90001--UP

2шт.

18

1501 256 H1

BAR

SN: P90001--UP

2шт.

|$29

24 841 R1

BOLT

SN: P90001--UP

2шт.

|$30

25 698 R1

BOLT

SN: P90001--UP

2шт.

|$31

9413 979

NUT

SN: P90001--UP

2шт.

|$32

9413 983

NUT

SN: P90001--UP

2шт.

19

PIN (SEE FIG. T2120-01A0)

SN: P90001--UP

2шт.

|$34

-1шт.

|$35

F1 PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$36

-1шт.
