Запчасти Komatsu D87E-2 FIG. K-A ПАНЕЛЬ ПРИБОРОВ КОЖУХ КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

1500 320 H91

PANEL AND SHROUD, INSTRUMENT

SN: P090001-UP

1шт.

1

PANEL (SEE FIG. K2210-02A1)

SN: P090001-UP

1шт.

2

702 439 C1

MOUNT, ISOLATION

SN: P090001-UP

4шт.

|$3

25 542 R1

WASHER

SN: P090001-UP

8шт.

|$4

25 519 R1

NUT

SN: P090001-UP

8шт.

3

1315 312 H1

SHIELD, FRONT

SN: P090001-UP

1шт.

|$6

1315 304 H1

SCREW

SN: P090001-UP

6шт.

4

1315 313 H1

SHIELD, REAR

SN: P090001-UP

1шт.

5

1500 324 H91

HARNESS

SN: P090001-UP

1шт.

6

145 705 H1

GROMMET

SN: P090001-UP

1шт.

|$10

-1шт.

|$11

F1 PART NUMBER IS A NON-SERVICE PART AND IS FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$12

-1шт.
