FIG. K7-A ОБОГРЕВАТЕЛЬ./PRESSURIZER ASSEMBLY

Запчасти Komatsu D87E-2 FIG. K7-A ОБОГРЕВАТЕЛЬ./PRESSURIZER ASSEMBLY КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

Схема запчастей Komatsu D87E-2 - FIG. K7-A ОБОГРЕВАТЕЛЬ./PRESSURIZER ASSEMBLY КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ
6
9
16
7
16
17
15
14
2
34
19
37
35
12
3
8
22
4
13
30
28
29
24
1
33
18
31
26
21
26
24
25
20
26
23
5
39
36
11
10
26
32
38
27
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$0

1313 781 H92

ASSEMBLY, HEATER/PRESSURIZER

SN: P090001-UP

1шт.

1

432 610

PLUG, BUTTON

SN: P090001-UP

3шт.

2

1437 224 H91

COIL, HEATER

SN: P090001-UP

1шт.

|$3

1439 635 H1

SCREW, TORX M6x16

SN: P090001-UP

4шт.

|$4

LA 0 729

NUT, JAM - 7/8-14

SN: P090001-UP

1шт.

|$5

1437 230 H1

WASHER, LOCK - 7/8

SN: P090001-UP

1шт.

3

1439 699 H1

MOTOR, BLOWER

SN: P090001-UP

2шт.

|$7

31 107 R1

LOCKNUT - M6

SN: P090001-UP

6шт.

4

LA 0 692

RING, ORIFICE

SN: P090001-UP

2шт.

|$9

1500 083 H1

LOCKNUT, #10

SN: P090001-UP

4шт.

5

1500 071 H1

CLIP, CABLE

SN: P090001-UP

1шт.

|$11

1500 084 H1

SCREW, HEX SLF TP

SN: P090001-UP

1шт.

6

1500 067 H1

ANGLE, LUG

SN: P090001-UP

1шт.

7

1500 068 H1

ANGLE, LUG

SN: P090001-UP

1шт.

8

1500 074 H1

BRACKET, MOTOR MOUNTING

SN: P090001-UP

4шт.

9

1316 361 H1

PLATE, COVER

SN: P090001-UP

1шт.

|$16

01010-81015

BOLT

SN: P090001-UP

11шт.

|$17

1314 067 H1

WASHER, HDN - M10

SN: P090001-UP

11шт.

10

1500 075 H1

BRACKET, CABLE LEVER

SN: P090001-UP

1шт.

|$19

1500 087 H1

SCREW, PAN HD - #8x7/16

SN: P090001-UP

4шт.

11

1500 076 H1

PLATE, CABLE LEVER

SN: P090001-UP

1шт.

|$21

LA 0 724

CLIP, COMPRESSION

SN: P090001-UP

1шт.

|$22

1500 062 H1

PUSHNUT, 1/4

SN: P090001-UP

1шт.

12

1270 184 H1

GASKET

SN: P090001-UP

2шт.

13

1500 077 H1

SEAL

SN: P090001-UP

1шт.

14

1439 622 H1

GASKET, TOP COIL

SN: P090001-UP

1шт.

15

1439 623 H1

GASKET, BOTTOM COIL

SN: P090001-UP

1шт.

|$27

1500 096 H91

PLATE, HEATER BLOCK-OFF

SN: P090001-UP

1шт.

16

1500 069 H1

GASKET, SPACER

SN: P090001-UP

2шт.

17

1500 080 H1

GASKET, COVER

SN: P090001-UP

1шт.

18

1500 097 H1

PLUG, BUTTON

SN: P090001-UP

1шт.

19

1316 363 H1

GASKET, BOTTOM

SN: P090001-UP

1шт.

20

1316 365 H1

CASE

SN: P090001-UP

1шт.

21

HOSE - 121.9MM(4.8 IN)

SN: P090001-UP

1шт.

22

938 514 C1

BLOWER, WHEEL

SN: P090001-UP

2шт.

23

1314 055 H1

DECAL, WATER FLOW

SN: P090001-UP

1шт.

24

1439 633 H1

WASHER, CENTERING

SN: P090001-UP

2шт.

25

LA 0 716

WASHER, RUBBER

SN: P090001-UP

2шт.

26

1439 634 H1

CLAMP

SN: P090001-UP

4шт.

27

08034-20519

STRAP, TIE

SN: P090001-UP

3шт.

28

LA 0 722

DECAL, NAMEPLATE

SN: P090001-UP

1шт.

29

30 325 R1

WASHER, FLAT - M6

SN: P090001-UP

7шт.

30

NUT, NYLON - #8-32

SN: P090001-UP

2шт.

|$43

57 227

WASHER, LOCK - #8

SN: P090001-UP

2шт.

|$44

1439 680 H1

SCREW, #8-32

SN: P090001-UP

2шт.

31

LA 0 738

RESISTOR

SN: P090001-UP

1шт.

|$46

LA 0 718

SCREW, 1/4-20x7.5

SN: P090001-UP

1шт.

32

1500 085 H91

HARNESS, WIRE

SN: P090001-UP

1шт.

33

1500 090 H91

VALVE, WATER

SN: P090001-UP

1шт.

34

1439 691 H91

HOUSING, BLOWER

SN: P090001-UP

2шт.

|$50

1439 632 H1

CLIP, BLOWER WHEEL

SN: P090001-UP

2шт.

35

1500 092 H91

OUTLET, RIGHT AIR

SN: P090001-UP

1шт.

|$52

1500 086 H1

SCREW, #10 TAPPING

SN: P090001-UP

4шт.

36

1500 093 H91

OUTLET, LEFT AIR

SN: P090001-UP

1шт.

|$54

1500 086 H1

SCREW, #10 TAPPING

SN: P090001-UP

4шт.

37

1316 364 H1

ANGLE

SN: P090001-UP

1шт.

38

1431 254 H1

FITTING

SN: P090001-UP

2шт.

39

HOSE - 259.1MM(10.2 IN)

SN: P090001-UP

1шт.

|$58

-1шт.

|$59

F1 MAKE FROM BULK HOSE 364 359 C1.

-1шт.

|$60

-1шт.
