Запчасти Komatsu D87E-2 FIG. K7-A ОБОГРЕВАТЕЛЬ./PRESSURIZER КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

1500 808 H91

HEATER/PRESSURIZER

SN: P090001-UP

1шт.

1

1500 874 H91

BRACKET

SN: P090001-UP

3шт.

|$2

30 019 R1

BOLT

SN: P090001-UP

3шт.

|$3

30 184 R1

WASHER

SN: P090001-UP

3шт.

2

HEATER (SEE FIG. K0710-05A0)

SN: P090001-UP

1шт.

|$5

30 021 R1

BOLT

SN: P090001-UP

2шт.

|$6

30 176 R1

WASHER

SN: P090001-UP

4шт.

3

1299 252 H1

HOSE

SN: P090001-UP

2шт.

4

182 088 H1

CLAMP

SN: P090001-UP

4шт.

5

1206 602 H1

HOSE

SN: P090001-UP

2шт.

6

314 798 R1

CLIP

SN: P090001-UP

7шт.

7

864 456 R1

ELBOW

SN: P090001-UP

1шт.

8

627 686 C1

VALVE, SHUTOFF

SN: P090001-UP

2шт.

9

1500 485 H1

NIPPLE-REDUCER

SN: P090001-UP

2шт.

10

864 456 R1

ELBOW

SN: P090001-UP

1шт.

11

27 702 R1

CLIP

SN: P090001-UP

4шт.

12

1500 873 H91

BRACKET

SN: P090001-UP

1шт.

|$17

30 019 R1

BOLT

SN: P090001-UP

1шт.

|$18

-1шт.

|$19

F1 PART NUMBER IS A NON-SERVICE PART AND IS FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$20

-1шт.
