Запчасти Komatsu D87E-2 FIG. K7-A КОНДИЦ. ВОЗДУХА/ЛИНИЯ ОБОГРЕВАТЕЛЯS КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

1500 477 H91

AIR CONDITIONER/HEATER

SN: P090001-UP

1шт.

1

1500 874 H91

BRACKET

SN: P090001-UP

3шт.

|$2

30 019 R1

BOLT

SN: P090001-UP

4шт.

|$3

30 184 R1

NUT

SN: P090001-UP

4шт.

2

1299 092 H91

CONDENSER

SN: P090001-UP

1шт.

|$5

275 804 R1

BOLT

SN: P090001-UP

4шт.

|$6

618 209 C1

WASHER

SN: P090001-UP

4шт.

3

1299 041 H1

SPACER

SN: P090001-UP

4шт.

4

1299 040 H1

WASHER

SN: P090001-UP

8шт.

5

1501 181 H1

HOSE

SN: P090001-UP

1шт.

6

1500 480 H1

HOSE

SN: P090001-UP

1шт.

7

1313 426 H1

HOSE

SN: P090001-UP

1шт.

8

1313 485 H91

DRIER/RECEIVER

SN: P090001-UP

1шт.

9

1313 427 H1

HOSE

SN: P090001-UP

1шт.

10

AIR CONDITIONER (SEE FIG. K0710-04A0)

SN: P090001-UP

1шт.

|$15

30 021 R1

BOLT

SN: P090001-UP

2шт.

|$16

30 176 R1

WASHER

SN: P090001-UP

4шт.

11

1299 252 H1

HOSE

SN: P090001-UP

2шт.

12

182 088 H1

CLAMP

SN: P090001-UP

4шт.

13

1206 602 H1

HOSE

SN: P090001-UP

2шт.

14

314 798 R1

CLIP

SN: P090001-UP

10шт.

15

864 456 R1

ELBOW

SN: P090001-UP

1шт.

16

627 686 C1

VALVE, SHUTOFF

SN: P090001-UP

2шт.

17

1500 485 H1

NIPPLE-REDUCER

SN: P090001-UP

2шт.

18

864 456 R1

ELBOW

SN: P090001-UP

1шт.

19

27 702 R1

CLIP

SN: P090001-UP

4шт.

20

154-Z11-5293

BRACKET

SN: P090001-UP

1шт.

|$27

01010-81030

BOLT

SN: P090001-UP

8шт.

|$28

01643-31032

WASHER

SN: P090001-UP

4шт.

|$29

203-54-56970

WASHER

SN: P090001-UP

4шт.

|$30

01011-81010

BOLT

SN: P090001-UP

1шт.

|$31

01643-31032

WASHER

SN: P090001-UP

1шт.

21

154-911-1170

BRACKET

SN: P090001-UP

1шт.

|$33

01010-80885

BOLT

SN: P090001-UP

2шт.

|$34

10E-60-25120

BOLT

SN: P090001-UP

2шт.

|$35

01643-30823

WASHER

SN: P090001-UP

4шт.

|$36

130-Z79-1740

BOLT

SN: P090001-UP

1шт.

|$37

01580-11008

NUT

SN: P090001-UP

1шт.

22

COMPRESSOR, REFRIGERANT (SEE FIG. K0710-02A0)

SN: P090001-UP

1шт.

23

04120-21756

V-BELT

SN: P090001-UP

1шт.

24

1500 814 H91

GUARD, BELT

SN: P090001-UP

1шт.

|$41

01010-81020

BOLT

SN: P090001-UP

3шт.

|$42

01643-31032

WASHER

SN: P090001-UP

3шт.

25

154-911-1190

PLATE

SN: P090001-UP

2шт.

26

20Y-979-3140

O-RING

SN: P090001-UP

2шт.

27

04434-51812

CLIP

SN: P090001-UP

2шт.

|$46

01010-81020

BOLT

SN: P090001-UP

2шт.

|$47

01643-31232

WASHER

SN: P090001-UP

2шт.

28

20Y-979-3130

O-RING

SN: P090001-UP

2шт.

29

1500 478 H1

FITTING

SN: P090001-UP

1шт.

|$50

30 195 R1

BOLT

SN: P090001-UP

1шт.

|$51

30 209 R1

WASHER

SN: P090001-UP

1шт.

30

1500 479 H1

FITTING

SN: P090001-UP

1шт.

|$53

30 195 R1

BOLT

SN: P090001-UP

1шт.

|$54

30 209 R1

WASHER

SN: P090001-UP

1шт.

31

04434-51512

CLIP

SN: P090001-UP

1шт.

32

1500 872 H91

ANGLE

SN: P090001-UP

1шт.

|$57

30 019 R1

BOLT

SN: P090001-UP

1шт.

|$58

30 184 R1

WASHER

SN: P090001-UP

1шт.

33

195-Z11-7250

CLIP

SN: P090001-UP

3шт.

|$60

30 019 R1

BOLT

SN: P090001-UP

3шт.

|$61

30 184 R1

WASHER

SN: P090001-UP

3шт.

34

1500 873 H91

BRACKET

SN: P090001-UP

1шт.

|$63

30 019 R1

BOLT

SN: P090001-UP

1шт.

|$64

30 184 R1

WASHER

SN: P090001-UP

1шт.

35

04434-51512

CLIP

SN: P090001-UP

3шт.

|$66

24 839 R1

BOLT

SN: P090001-UP

8шт.

|$67

25 544 R1

WASHER

SN: P090001-UP

8шт.

36

195-Z11-7250

CLIP

SN: P090001-UP

1шт.

|$69

30 019 R1

BOLT

SN: P090001-UP

1шт.

|$70

30 184 R1

WASHER

SN: P090001-UP

1шт.

|$71

30 168 R1

NUT

SN: P090001-UP

1шт.

37

1313 431 H91

CLAMP

SN: P090001-UP

2шт.

|$73

24 839 R1

BOLT

SN: P090001-UP

2шт.

|$74

25 544 R1

WASHER

SN: P090001-UP

3шт.

|$75

25 522 R1

NUT

SN: P090001-UP

2шт.

38

1313 434 H1

CLAMP

SN: P090001-UP

2шт.

|$77

24 839 R1

BOLT

SN: P090001-UP

2шт.

|$78

25 544 R1

WASHER

SN: P090001-UP

3шт.

|$79

25 522 R1

NUT

SN: P090001-UP

2шт.

|$80

-1шт.

|$81

F1 PART NUMBER IS A NON-SERVICE PART AND IS FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$82

-1шт.
