Запчасти Komatsu D87E-2 FIG. K-A КАБИНА - БАЧОК ОМЫВАТЕЛЯСИСТЕМА КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

1298 893 H1

TANK, WASHER

SN: P090001-UP

2шт.

|$1

22 470 R1

BOLT

SN: P090001-UP

4шт.

|$2

934 946 R1

WASHER

SN: P090001-UP

8шт.

|$3

25 519 R1

NUT

SN: P090001-UP

4шт.

2

1212 589 H1

PUMP

SN: P090001-UP

2шт.

3

1214 181 H1

CAP, FILLER

SN: P090001-UP

3шт.

4

1211 216 H1

SPOUT

SN: P090001-UP

1шт.

|$7

30 590 R1

SCREW

SN: P090001-UP

2шт.

|$8

30 481 R1

WASHER

SN: P090001-UP

2шт.

5

446 075 R91

CLIP

SN: P090001-UP

1шт.

6

TUBE, SPOUT TO TEE(900MM - 35.5 IN LONG)

SN: P090001-UP

1шт.

7

TUBE (940MM - 37 IN LONG)

SN: P090001-UP

1шт.

8

935 522 C1

STRAP

SN: P090001-UP

4шт.

9

1212 696 H1

FITTING, TEE

SN: P090001-UP

1шт.

10

TUBE

SN: P090001-UP

-2шт.

11

TUBE

SN: P090001-UP

-2шт.

12

1277 932 H1

FITTING, TEE

SN: P090001-UP

3шт.

13

TUBE - PUMP TO TEE (3987MM - 157 IN LONG)

SN: P090001-UP

1шт.

14

TUBE - PUMP TO TEE (3479MM - 137 IN LONG)

SN: P090001-UP

1шт.

15

TUBE - TEE TO FRONT OR REAR WIPER (1955MM - 77 IN LONG)

SN: P090001-UP

2шт.

16

TUBE - TEE TO LEFT OR RIGHT WIPER (3098MM - 122 IN LONG)

SN: P090001-UP

2шт.

17

1313 410 H2

BRACKET, WASHER TANK

SN: P090001-UP

1шт.

|$22

30 020 R1

BOLT

SN: P090001-UP

2шт.

|$23

30 176 R1

WASHER

SN: P090001-UP

2шт.

18

28 135 R1

CLIP, CLOSED

SN: P090001-UP

1шт.

|$25

30 041 R1

BOLT

SN: P090001-UP

1шт.

|$26

30 185 R1

WASHER

SN: P090001-UP

1шт.

19

07285-00220

CLIP, HOSE

SN: P090001-UP

5шт.

|$28

OR

SN: P090001-UP

-1шт.

|$29

27 861 R1

CLIP, HOSE

SN: P090001-UP

5шт.

20

07285-00068

CLIP, HOSE

SN: P090001-UP

2шт.

|$31

-1шт.

|$32

F1 CUT FROM BULK HOSE 1315 762 H1.

-1шт.

|$33

-1шт.

|$34

-1шт.

|$35

F2 CUT FROM BULK HOSE 940 455 C2.

-1шт.

|$36

-1шт.

|$37

-1шт.

|$38

F3 CUT FROM BULK HOSE 364 359 C1.

-1шт.

|$39

-1шт.
