Запчасти Komatsu D87E-2 FIG. J-A ЗАЩИТА РАДИАТОРА AND ПЕРЕДН. STRIKER BARS - LANDFILL PACKAGE ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

1

1316 086 H91

DOOR, RIGHT RADIATOR

SN: P090001-UP

1шт.

2

1316 087 H91

DOOR, LEFT RADIATOR

SN: P090001-UP

1шт.

3

1316 014 H91

HINGE

SN: P090001-UP

4шт.

|$3

24 888 R1

BOLT, HEX - 3/4NCX2

SN: P090001-UP

8шт.

|$4

25 557 R1

WASHER - 3/4

SN: P090001-UP

8шт.

|$5

24 892 R1

BOLT, HEX - 3/4NCX3

SN: P090001-UP

4шт.

|$6

9413 983

NUT, LOCK - 3/4NC

SN: P090001-UP

4шт.

4

17A-54-A0165

PLATE

SN: P090001-UP

2шт.

5

17A-54-A0175

SPACER

SN: P090001-UP

2шт.

|$9

24 862 R1

BOLT, HEX - 1/2NCX1-1/2

SN: P090001-UP

2шт.

|$10

25 555 R1

WASHER - 1/2

SN: P090001-UP

2шт.

6

17A-54-A0145

LATCH ASSEMBLY

SN: P090001-UP

2шт.

|$12

24 841 R1

BOLT, HEX - 3/8NCX1-1/2

SN: P090001-UP

4шт.

|$13

25 553 R1

WASHER - 3/8

SN: P090001-UP

4шт.

|$14

9413 979

NUT, LOCK - 3/8

SN: P090001-UP

4шт.

7

17A-54-A0155

PAWL

SN: P090001-UP

2шт.

|$16

9413 957

NUT, LOCK - 1/2

SN: P090001-UP

4шт.

|$17

25 281 R1

BOLT, HEX - 1/2NCX2-3/4

SN: P090001-UP

4шт.

|$18

25 555 R1

WASHER - 1/2

SN: P090001-UP

4шт.

8

1316 085 H91

MASK

SN: P090001-UP

1шт.

9

1316 083 H91

STRIKER, RIGHT

SN: P090001-UP

1шт.

|$21

25 845 R1

BOLT, HEX - 1NCX2-1/2

SN: P090001-UP

10шт.

|$22

25 550 R1

WASHER - 1

SN: P090001-UP

10шт.

10

1316 084 H91

STRIKER, LEFT

SN: P090001-UP

1шт.

|$24

25 845 R1

BOLT, HEX - 1NCX2-1/2

SN: P090001-UP

10шт.

|$25

25 550 R1

WASHER - 1

SN: P090001-UP

10шт.
