Запчасти Komatsu D87E-2 FIG. J-A ОСНОВН. РАМА И КОМПОНЕНТЫ ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

|$0

1315 531 H91

FRAME ASSEMBLY, MAIN

SN: P090001-UP

1шт.

1

1315 068 H91

FRAME, MAIN

SN: P090001-UP

1шт.

2

655 417 C1

BUSHING

SN: P090001-UP

2шт.

3

651 272 C1

PLUG, DRAIN

SN: P090001-UP

3шт.

4

59 658 D

WASHER, DRAIN PLUG

SN: P090001-UP

3шт.

5

733 039 C1

COVER, PTO

SN: P090001-UP

1шт.

|$7

OR

-1шт.

|$9

1208 404 H1

COVER, PTO

SN: P090001-UP

1шт.

|$10

24 871 R1

BOLT, HEX - 5/8NCx1

SN: P090001-UP

5шт.

|$11

25 976 R1

WASHER, FLAT - 5/8

SN: P090001-UP

5шт.

6

22 420 R1

RING, SEAL

SN: P090001-UP

1шт.

|$14

OR

-1шт.

|$16

22 400 R1

RING, SEAL

SN: P090001-UP

1шт.

|$17

1500 878 H91

REAR COVER PLATE

SN: P090001-UP

1шт.

7

1262 997 H1

PLATE, FRAME COVER TOP

SN: P090001-UP

1шт.

8

628 971 C1

TUBE, OIL LEVEL GAUGE & OIL FILLER

SN: P090001-UP

1шт.

|$20

26 510 R1

BOLT, HEX - 5/8NCx1-1/2.

SN: P090001-UP

26шт.

|$21

25 537 R1

WASHER, FLAT - 5/8

SN: P090001-UP

26шт.

9

628 972 C2

SLEEVE, OIL LEVEL GAUGE

SN: P090001-UP

1шт.

|$23

27 431 R1

BOLT, HEX - 3/8NCx1/2.

SN: P090001-UP

1шт.

|$24

25 534 R1

WASHER, FLAT - 3/8

SN: P090001-UP

1шт.

10

628 974 C1

BRACKET, SLEEVE SUPPORT

SN: P090001-UP

1шт.

|$26

27 431 R1

BOLT, HEX - 3/8NCx1/2.

SN: P090001-UP

1шт.

|$27

25 534 R1

WASHER, FLAT - 3/8

SN: P090001-UP

1шт.

11

628 975 C3

GAUGE, OIL LEVEL

SN: P090001-UP

1шт.

12

662 250 C1

BREATHER, REAR MAIN FRAME

SN: P090001-UP

1шт.

|$30

OR

SN: P090001-UP

-1шт.

|$31

666 156 C1

BREATHER, REAR MAIN FRAME

SN: P090001-UP

1шт.

13

179 752

COUPLING, PIPE

SN: P090001-UP

1шт.

14

219 645

NIPPLE, PIPE

SN: P090001-UP

1шт.

15

1110 878 C1

MAGNET

SN: P090001-UP

1шт.

16

TUBE, GIMBAL (SEE FIG. M2111-01A0)

SN: P090001-UP

1шт.

17

MASK, FRONT (SEE FIG. M2120-01A0)

SN: P090001-UP

1шт.

18

117 926

PLUG, CORK

SN: P090001-UP

14шт.

19

454 141

TEE

SN: P090001-UP

1шт.

20

444 033

REDUCER

SN: P090001-UP

1шт.

21

9403 098

TEE

SN: P090001-UP

1шт.

|$41

-1шт.

|$42

F1 PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$43

-1шт.
