Запчасти Komatsu D87E-2 FIG. H-A РЫХЛИТЕЛЬ LIFT ТРУБЫ ГИДРАВЛИКА

|$0

1500 449 H91

PIPING, RIPPER LIFT

SN: P90001--UP

1шт.

1

HOSE (SEE FIG. H0100-08A1)

SN: P90001--UP

1шт.

2

HOSE (SEE FIG. H0100-08A1)

SN: P90001--UP

1шт.

3

738 563 C1

TUBE

SN: P90001--UP

1шт.

4

1303 365 H91

TUBE

SN: P90001--UP

1шт.

5

717 715 C1

BRACKET

SN: P90001--UP

1шт.

|$6

24 861 R1

BOLT

SN: P90001--UP

2шт.

|$7

25 536 R1

WASHER

SN: P90001--UP

2шт.

6

717 716 C1

BRACKET

SN: P90001--UP

1шт.

|$9

24 861 R1

BOLT

SN: P90001--UP

2шт.

|$10

25 536 R1

WASHER

SN: P90001--UP

2шт.

7

734 750 C1

CLAMP

SN: P90001--UP

2шт.

|$12

24 843 R1

BOLT

SN: P90001--UP

2шт.

|$13

25 553 R1

WASHER

SN: P90001--UP

2шт.

8

705 935 C1

BLOCK

SN: P90001--UP

2шт.

9

380 794 R1

O-RING

SN: P90001--UP

10шт.

10

283 172 R1

FLANGE

SN: P90001--UP

16шт.

|$17

140 483 H

BOLT

SN: P90001--UP

32шт.

11

717 717 C1

HOSE

SN: P90001--UP

4шт.

12

306 132 C2

STRAP

SN: P90001--UP

3шт.

13

CYLINDER (SEE FIG. T2460-01A0)

SN: P90001--UP

2шт.

14

710 438 C1

TUBE

SN: P90001--UP

2шт.

|$22

140 483 H

BOLT

SN: P90001--UP

4шт.

|$23

24 843 R1

BOLT

SN: P90001--UP

4шт.

15

602 449 C1

CLAMP

SN: P90001--UP

2шт.

|$25

24 839 R1

BOLT

SN: P90001--UP

4шт.

|$26

25 534 R1

WASHER

SN: P90001--UP

4шт.

16

1500 826 H1

HOSE

SN: P90001--UP

1шт.

17

9410 202

CONNECTOR

SN: P90001--UP

1шт.

18

364 839 R1

O-RING

SN: P90001--UP

1шт.

19

299 413 C1

CLIP

SN: P90001--UP

3шт.

|$31

931 463 R1

BOLT

SN: P90001--UP

3шт.

|$32

25 544 R1

WASHER

SN: P90001--UP

3шт.

|$33

-1шт.

|$34

F1 PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$35

-1шт.
