Запчасти Komatsu D87E-2 FIG. H-A ОТВАЛ ГЛАВН. КЛАПАН ГИДРАВЛИКА

|$0

1316 046 H91

VALVE ASSEMBLY, BLADE PILOT

SN: P90001--UP

1шт.

1

1234 007 H1

BOOT, VALVE

SN: P90001--UP

1шт.

2

1237 469 H1

NUT, CONTROL

SN: P90001--UP

1шт.

3

1287 846 H2

PLATE, PIVOT

SN: P90001--UP

1шт.

4

1287 845 H1

JOINT, PIVOT

SN: P90001--UP

1шт.

5

1234 008 H1

CLAMP, BOOT

SN: P90001--UP

1шт.

6

1237 498 H1

PLATE, MOUNTING

SN: P90001--UP

1шт.

7

24 844 R1

BOLT, MOUNTING - 3/8NCx3-1/2

SN: P90001--UP

2шт.

8

1101 967 C1

SCREW MOUNTING - 5/16NCx3/4

SN: P90001--UP

1шт.

9

157 911 H1

WASHER, FLAT - 21/64 IDx3/4OD

SN: P90001--UP

1шт.

10

1237 467 H1

ACTUATOR, PLUNGER

SN: P90001--UP

4шт.

11

1237 473 H2

SLEEVE, ACTUATOR

SN: P90001--UP

3шт.

12

1237 475 H1

SLEEVE, MAGNETIC

SN: P90001--UP

1шт.

13

NSS

HOUSING, UPPER

SN: P90001--UP

1шт.

14

1237 471 H1

CLAPPER, SPRING RETAINER

SN: P90001--UP

4шт.

15

1237 468 H1

SPRING, CLAPPER - 2 IN. LONG

SN: P90001--UP

2шт.

16

1237 470 H1

SPRING, CLAPPER - 2 -1/4 IN. LONG

SN: P90001--UP

2шт.

17

1245 583 H1

SPACER

SN: P90001--UP

4шт.

18

CAPSULE, PLUNGER (SEE FIG. H0120-03A0)

SN: P90001--UP

1шт.

19

CAPSULE, PLUNGER FEEL (SEE FIG. H0120-04A0)

SN: P90001--UP

1шт.

20

NSS

HOUSING, LOWER

SN: P90001--UP

1шт.

21

CAPSULE, METERING (SEE FIG. H0120-05A0)

SN: P90001--UP

4шт.

22

CAPSULE, PLUNGER (SEE FIG. H0120-03A1)

SN: P90001--UP

2шт.

|$23

1285 312 H1

KIT, GASKET

SN: P90001--UP

1шт.

|$24

-1шт.

|$26

-1шт.
