Запчасти Komatsu D87E-2 FIG. F-A ТРАНСМИССИЯ - КОЖУХ И INTERNAL ЧАСТИ СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

635 580 C92

TRANSMISSION ASSEMBLY.

SN: P090001-UP

1шт.

1

709 508 C1

COVER

SN: P090001-UP

1шт.

|$2

24 863 R1

BOLT

SN: P090001-UP

15шт.

|$3

25 536 R1

WASHER

SN: P090001-UP

15шт.

2

GEAR, REVERSE IDLER (SEE FIG. F2320-04A0)

SN: P090001-UP

1шт.

3

COUNTERSHAFT (SEE FIG. F2320-05A0)

SN: P090001-UP

1шт.

4

659 571 C1

SUPPORT, MANIFOLD-SHORT

SN: P090001-UP

1шт.

5

371 544 R1

O-RING

SN: P090001-UP

6шт.

6

659 835 C1

RING, OUTER SEAL

SN: P090001-UP

6шт.

7

654 685 C1

TUBE, SUPPLY-SHORT

SN: P090001-UP

3шт.

8

659 835 C1

RING, OUTER SEAL

SN: P090001-UP

8шт.

9

371 544 R1

O-RING

SN: P090001-UP

8шт.

10

654 686 C1

TUBE, SUPPLY-LONG

SN: P090001-UP

4шт.

11

CLUTCH, DIRECTIONAL (SEE FIG. F2320-06A0)

SN: P090001-UP

1шт.

12

709 586 C1

SUPPORT, MANIFOLD-LONG

SN: P090001-UP

1шт.

13

27 002 R1

BOLT

SN: P090001-UP

2шт.

14

CLUTCH, RANGE (SEE FIG. F2320-03A0)

SN: P090001-UP

1шт.

15

125 860

PIN, DOWEL

SN: P090001-UP

2шт.

16

654 678 C91

HOUSING W/DOWELS

SN: P090001-UP

1шт.

17

22 413 R1

O-RING

SN: P090001-UP

3шт.

18

659 630 C1

SHIM - 127MM(.005 IN)

SN: P090001-UP

-2шт.

|$22

OR

-1шт.

|$24

659 719 C1

SHIM - 178MM(.007 IN)

SN: P090001-UP

-2шт.

|$26

OR

-1шт.

|$28

659 629 C1

SHIM - 508MM(.020 IN)

SN: P090001-UP

-2шт.

19

654 303 C1

COVER

SN: P090001-UP

2шт.

|$30

140 483 H

BOLT

SN: P090001-UP

7шт.

|$31

25 534 R1

WASHER

SN: P090001-UP

7шт.

20

444 697

PLUG

SN: P090001-UP

3шт.

21

659 566 C1

SHIM - 508MM(.020 IN)

SN: P090001-UP

4шт.

|$35

OR

-1шт.

|$37

659 567 C1

SHIM - 127MM(.005 IN)

SN: P090001-UP

-2шт.

|$39

OR

-1шт.

|$41

659 733 C1

SHIM - 178MM(.007 IN)

SN: P090001-UP

-2шт.

22

654 681 C1

COVER

SN: P090001-UP

1шт.

|$43

140 483 H

BOLT

SN: P090001-UP

7шт.

|$44

25 534 R1

WASHER

SN: P090001-UP

7шт.

23

619 586 C91

SEAL, OIL

SN: P090001-UP

1шт.

24

21 924 R1

O-RING

SN: P090001-UP

1шт.

25

709 552 C2

STRAINER

SN: P090001-UP

1шт.

|$48

26 309 R1

BOLT

SN: P090001-UP

2шт.

26

22 288 R1

O-RING

SN: P090001-UP

1шт.

27

709 517 C1

FLANGE

SN: P090001-UP

1шт.

|$51

-1шт.

|$52

F1 PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$53

-1шт.
