Запчасти Komatsu D87E-2 FIG. F-A УПРАВЛ-Е ТРАНСМИССИЕЙ ТРУБЫ СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

1316 503 H91

TRANSMISSION CONTROL PIPING

SN: P090001-UP

1шт.

1

HOUSING, TRANSMISSION (SEE FIG. F2320-02A0)

SN: P090001-UP

1шт.

2

VALVE, PRESSURE REGULATOR (SEE FIG. F2320-11A0)

SN: P090001-UP

1шт.

|$3

24 845 R1

BOLT

SN: P090001-UP

3шт.

|$4

115 093

WASHER, LOCK

SN: P090001-UP

3шт.

3

VALVE, RANGE SELECTOR (SEE FIG. F2320-12A0)

SN: P090001-UP

1шт.

|$6

25 501 R1

BOLT

SN: P090001-UP

3шт.

|$7

115 093

WASHER, LOCK

SN: P090001-UP

3шт.

4

VALVE, RATE OF RISE (SEE FIG. F2320-13A0)

SN: P090001-UP

1шт.

|$9

24 846 R1

BOLT

SN: P090001-UP

1шт.

|$10

25 501 R1

BOLT

SN: P090001-UP

3шт.

|$11

115 093

WASHER, LOCK

SN: P090001-UP

4шт.

5

444 613

PLUG, PIPE

SN: P090001-UP

1шт.

6

659 202 C2

GASKET

SN: P090001-UP

1шт.

7

659 201 C2

MANIFOLD, VALVES

SN: P090001-UP

1шт.

|$15

27 077 R1

BOLT

SN: P090001-UP

6шт.

|$16

24 843 R1

BOLT

SN: P090001-UP

7шт.

|$17

115 093

WASHER. LOCK

SN: P090001-UP

7шт.

8

252 707 R1

O-RING

SN: P090001-UP

11шт.

9

350 429 R1

O-RING

SN: P090001-UP

1шт.

10

372 821 R1

O-RING

SN: P090001-UP

2шт.

11

657 951 C3

GASKET

SN: P090001-UP

1шт.

12

738 058 C1

STRAINER, ORIFICE

SN: P090001-UP

1шт.

|$24

OR

-1шт.

|$26

738 444 C1

STRAINER, ORIFICE

SN: P090001-UP

1шт.

13

296 247 R1

O-RING

SN: P090001-UP

3шт.

14

666 268 C1

TEE

SN: P090001-UP

1шт.

15

1210 977 H1

ELBOW

SN: P090001-UP

1шт.

16

666 280 C1

ELBOW

SN: P090001-UP

1шт.

17

28 071 R1

CONNECTOR

SN: P090001-UP

1шт.

18

26 155 R1

ELBOW

SN: P090001-UP

4шт.

19

667 931 C1

HOSE

SN: P090001-UP

5шт.

20

VALVE, TASC (SEE FIG. F2305-08A0)

SN: P090001-UP

1шт.

21

587 639 R1

CONNECTOR

SN: P090001-UP

3шт.

22

1316 408 H1

HOSE

SN: P090001-UP

2шт.

23

9403 098

TEE

SN: P090001-UP

1шт.

24

444 012

ADAPTER

SN: P090001-UP

1шт.

25

9402 825

ELBOW

SN: P090001-UP

1шт.

26

1316 450 H91

GUIDE, HOSE

SN: P090001-UP

1шт.

27

1298 547 H1

GROMMET

SN: P090001-UP

8шт.

28

570 828 R1

O-RING

SN: P090001-UP

3шт.

29

9411 104

CONNECTOR

SN: P090001-UP

3шт.

30

364 839 R1

O-RING

SN: P090001-UP

3шт.

31

9410 280

FITTING

SN: P090001-UP

1шт.

32

570 828 R1

O-RING

SN: P090001-UP

1шт.

33

9410 976

CONNECTOR

SN: P090001-UP

1шт.

34

364 839 R1

0-RING

SN: P090001-UP

1шт.

35

SWITCH, BACKUP ALARM (SEE FIG. E0400-04A0)

SN: P090001-UP

1шт.

36

9411 128

TEE

SN: P090001-UP

2шт.

37

369 751 R1

O-RING

SN: P090001-UP

2шт.

38

1316 407 H1

HOSE

SN: P090001-UP

1шт.

39

1316 409 H1

HOSE

SN: P090001-UP

2шт.

40

9410 977

CONNECTOR

SN: P090001-UP

1шт.

41

306 132 C2

STRAP

SN: P090001-UP

1шт.

42

1316 391 H1

HOSE

SN: P090001-UP

1шт.

43

9410 202

CONNECTOR

SN: P090001-UP

1шт.

44

364 839 R1

O-RING

SN: P090001-UP

1шт.

|$59

-1шт.

|$60

F1 PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS

-1шт.

|$61

-1шт.
