Запчасти Komatsu D87E-2 FIG. F-A ГИДРОТРАНСФОРМАТОР СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

1315 752 H91

CONVERTER, TORQUE

SN: P090001-UP

1шт.

1

932 507 C1

COVER, HOUSING

SN: P090001-UP

1шт.

|$2

151 629

BOLT, MOUNTING - 3/8NCx1

SN: P090001-UP

6шт.

|$3

103 321

WASHER, LOCK - 3/8

SN: P090001-UP

6шт.

2

921 825 C1

SHIM - 0.127MM (.005 IN)

SN: P090001-UP

-2шт.

|$5

921 826 C1

SHIM - 0.254MM (.010 IN)

SN: P090001-UP

-2шт.

|$6

921 827 C1

SHIM - 0.508MM (.020 IN)

SN: P090001-UP

-2шт.

3

156 362 H1

PLATE, RETAINING

SN: P090001-UP

1шт.

|$8

179 838

BOLT, MOUNTING - 3/8NCx7/8

SN: P090001-UP

3шт.

4

921 840 C2

WASHER, RETAINING

SN: P090001-UP

1шт.

5

ST 383

BEARING, BALL

SN: P090001-UP

1шт.

|$11

OR

SN: P090001-UP

-1шт.

|$12

747 409 C91

BEARING, BALL

SN: P090001-UP

1шт.

6

631 885 C1

HOUSING, DRIVE

SN: P090001-UP

1шт.

7

631 886 C91

TURBINE

SN: P090001-UP

1шт.

8

149 208 H1

BEARING, THRUST

SN: P090001-UP

2шт.

9

930 358 C1

WASHER, THRUST

SN: P090001-UP

1шт.

10

631 887 C91

STATOR ASSEMBLY

SN: P090001-UP

1шт.

11

NSS

STATOR

SN: P090001-UP

1шт.

12

18 400 R1

PIN, SPRING

SN: P090001-UP

2шт.

13

631 894 C1

RING, STATOR

SN: P090001-UP

1шт.

14

1113 196 C1

SPACER, BEARING

SN: P090001-UP

1шт.

15

719 815 C1

IMPELLER

SN: P090001-UP

1шт.

|$23

26 679 R1

BOLT, PREVAILING TORQUE - 5/16NCx2-1/4

SN: P090001-UP

24шт.

|$24

25 533 R1

WASHER, FLAT - 5/16

SN: P090001-UP

24шт.

16

130 006 H1

BEARING, BALL

SN: P090001-UP

1шт.

17

634 078 C1

GEAR, DRIVE

SN: P090001-UP

1шт.

|$27

OR

SN: P090001-UP

-1шт.

|$28

734 342 C1

GEAR, DRIVE

SN: P090001-UP

1шт.

|$29

27 261 R1

BOLT, PREVAILING TORQUE - 7/16NFx2-1/4

SN: P090001-UP

7шт.

|$30

25 535 R1

WASHER, FLAT - 7/16

SN: P090001-UP

7шт.

18

324 062 R2

RING, SEAL

SN: P090001-UP

1шт.

19

921 812 C4

HUB, GROUND SLEEVE

SN: P090001-UP

1шт.

20

324 069 R1

GASKET, RETAINER

SN: P090001-UP

1шт.

21

634 079 C1

GEAR, PUMP DRIVE

SN: P090001-UP

2шт.

22

ST 201

BEARING, BALL

SN: P090001-UP

4шт.

23

197 971 H1

RING, RETAINING

SN: P090001-UP

2шт.

24

631 255 R1

RING, RETAINING

SN: P090001-UP

2шт.

25

239 776 R1

RING, RETAINING

SN: P090001-UP

1шт.

26

892 228 C1

SLEEVE, SPLINED

SN: P090001-UP

1шт.

27

933 126 C1

RING, SEAL

SN: P090001-UP

1шт.

28

336 971 R1

RING, RETAINING

SN: P090001-UP

1шт.

29

ST 297

BEARING

SN: P090001-UP

1шт.

|$44

OR

-1шт.

|$46

1297 691 H91

BEARING

SN: P090001-UP

1шт.

30

631 890 C1

SHAFT, OUTPUT

SN: P090001-UP

1шт.

31

921 825 C1

SHIM - 0.127MM (.005 IN)

SN: P090001-UP

-2шт.

|$49

921 826 C1

SHIM - 0.254MM (.010 IN)

SN: P090001-UP

-2шт.

|$50

921 827 C1

SHIM - 0.508MM (.020 IN)

SN: P090001-UP

-2шт.

|$51

1108 155 C1

SHIM - 1.270MM (.050 IN)

SN: P090001-UP

-2шт.

32

324 069 R1

GASKET, RETAINER

SN: P090001-UP

1шт.

33

631 884 C1

RETAINER, BEARING

SN: P090001-UP

1шт.

|$54

179 848

BOLT, MOUNTING - 3/8NCx2-1/4

SN: P090001-UP

6шт.

|$55

103 321

WASHER, LOCK - 3/8

SN: P090001-UP

6шт.

34

333 996 R92

SEAL, OIL

SN: P090001-UP

1шт.

35

630 290 C1

FLANGE, OUTPUT

SN: P090001-UP

1шт.

36

324 072 R2

WASHER, RETAINING

SN: P090001-UP

1шт.

37

324 071 R2

PLATE, RETAINING

SN: P090001-UP

1шт.

|$60

454 869

BOLT, MOUNTING - 5/16NCx3/4

SN: P090001-UP

1шт.

38

NSS

HOUSING, CONVERTER

SN: P090001-UP

1шт.

39

625 854 C1

COVER, TOP

SN: P090001-UP

1шт.

|$63

179 881

BOLT, MOUNTING - 1/2NCx1

SN: P090001-UP

6шт.

|$64

103 323

WASHER, LOCK - 1/2

SN: P090001-UP

6шт.

40

627 396 C2

GASKET, COVER

SN: P090001-UP

1шт.

41

357 557 R1

PIN, SPRING

SN: P090001-UP

1шт.

42

930 369 C1

RING

SN: P090001-UP

1шт.

|$68

719 810 C91

KIT, SERVICE

SN: P090001-UP

1шт.

|$69

-1шт.

|$70

F1 PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$71

-1шт.

|$72

-1шт.

|$73

F2 PART OF SERVICE KIT 719 810 C91

-1шт.

|$74

-1шт.
