Запчасти Komatsu D87E-2 FIG. F-8A ТРАНСМИССИЯ/РУЛЕВ. УПРАВЛЕНИЕ УПРАВЛ-Е(TASC) КЛАПАН СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

1316 381 H91

VALVE ASSEMBLY, TRANS/STEER CONTROL

SN: P090001-UP

1шт.

1

NSS

VALVE, BODY

SN: P090001-UP

1шт.

2

1305 804 H1

PLUG, EXPANDER

SN: P090001-UP

5шт.

3

1220 721 H1

PLUG

SN: P090001-UP

2шт.

4

NSS

SPOOL, STEERING VALVE

SN: P090001-UP

2шт.

5

1308 033 H1

SPACER, PICKUP

SN: P090001-UP

2шт.

6

1308 045 H1

SPRING, INNER

SN: P090001-UP

2шт.

7

1308 046 H1

SPRING, OUTER

SN: P090001-UP

2шт.

8

NSS

SPOOL, DIRECTION

SN: P090001-UP

2шт.

9

1305 898 H1

WASHER, SPRING

SN: P090001-UP

2шт.

10

1308 048 H1

SPRING, FRONT-REAR

SN: P090001-UP

2шт.

11

1308 032 H1

NUT, STOP

SN: P090001-UP

2шт.

12

1305 742 H1

ROCKER END, SPOOL

SN: P090001-UP

4шт.

13

25 932 R1

NUT, JAM - 3/8NC

SN: P090001-UP

4шт.

14

NSS

SPOOL, RANGE

SN: P090001-UP

1шт.

15

1308 035 H1

BEARING, THRUST

SN: P090001-UP

1шт.

16

1308 036 H1

WASHER, THRUST

SN: P090001-UP

2шт.

17

23 112 R1

PIN, DOWEL

SN: P090001-UP

1шт.

18

25 526 R1

NUT, HEX - 1/2NC

SN: P090001-UP

1шт.

|$19

1308 060 H91

CAM ASSEMBLY, RANGE AND PIN

SN: P090001-UP

1шт.

19

21 247 R1

PIN, DOWEL

SN: P090001-UP

2шт.

20

20 702 R1

PIN, DOWEL

SN: P090001-UP

2шт.

21

NSS

CAM, RANGE

SN: P090001-UP

1шт.

|$23

1305 747 H91

COVER ASSY, BOTTOM

SN: P090001-UP

1шт.

22

NSS

COVER, BOTTOM

SN: P090001-UP

1шт.

23

1220 721 H1

PLUG, PORT

SN: P090001-UP

4шт.

|$26

277 232 R1

BOLT, HEX - 3/8NCx2-3/4

SN: P090001-UP

4шт.

|$27

25 544 R1

WASHER, FLAT - 3/8

SN: P090001-UP

4шт.

24

1243 919 H1

PLUG, ORIFICE

SN: P090001-UP

2шт.

25

20 702 R1

PIN, DOWEL

SN: P090001-UP

2шт.

26

1316 383 H1

LEVER, CONTROL

SN: P090001-UP

1шт.

27

1308 030 H1

BEARING, HOUSING

SN: P090001-UP

1шт.

|$32

25 483 R1

BOLT, HEX - 1/4NCx1

SN: P090001-UP

3шт.

|$33

25 532 R1

WASHER, FLAT - 1/4

SN: P090001-UP

3шт.

28

1305 754 H1

RING, CAM

SN: P090001-UP

1шт.

29

1308 038 H1

BEARING, BALL

SN: P090001-UP

2шт.

30

273 026 R1

RING, RETAINING

SN: P090001-UP

2шт.

|$37

1306 824 H91

JOINT ASSEMBLY, UNIVERSAL

SN: P090001-UP

1шт.

31

1308 049 H1

JOINT, UNIVERSAL

SN: P090001-UP

1шт.

32

1308 051 H1

BOOT, UNIVERSAL JOINT

SN: P090001-UP

1шт.

33

976 196 C1

STRAP, TIE

SN: P090001-UP

2шт.

34

19 967 R1

PIN, DOWEL

SN: P090001-UP

2шт.

35

17 008 R1

BALL - 1/4IN DIA

SN: P090001-UP

1шт.

36

1308 047 H3

SPRING, RANGE DETENT

SN: P090001-UP

1шт.

37

1305 820 H1

GUIDE, DETENT

SN: P090001-UP

1шт.

38

1312 778 H1

PLUG, DETENT GUIDE

SN: P090001-UP

1шт.

39

364 839 R1

RING, SEAL

SN: P090001-UP

1шт.

40

1305 806 H1

ARM, RING MAGNET

SN: P090001-UP

1шт.

41

1305 906 H1

MAGNET, CERAMIC RING

SN: P090001-UP

1шт.

42

1308 037 H1

SCREW, BRASS

SN: P090001-UP

1шт.

43

180 020

BOLT, HEX - 1/4NCx3/4

SN: P090001-UP

1шт.

44

1305 759 H1

WIPER, SPOOL

SN: P090001-UP

2шт.

45

1305 760 H1

WIPER, SPOOL

SN: P090001-UP

2шт.

46

1305 761 H1

WIPER, SPOOL

SN: P090001-UP

1шт.

47

384 937 R1

RING, SEAL

SN: P090001-UP

5шт.

48

384 376 R1

RING, SEAL

SN: P090001-UP

4шт.

49

21 098 R1

RING, SEAL

SN: P090001-UP

1шт.

50

1309 018 H1

COLLAR

SN: P090001-UP

1шт.

51

350 684 R1

RING, SEAL

SN: P090001-UP

1шт.

52

9410 359

PLUG

SN: P090001-UP

2шт.

53

570 828 R1

O-RING

SN: P090001-UP

2шт.
