Запчасти Komatsu D87E-2 FIG. F-A РУЛЕВ. УПРАВЛЕНИЕ УПРАВЛ-ЕS - ВЕРХН.(TWO SPEED) ИЛИ ОСНОВН. КЛАПАН РУЛЕВОГО УПРАВЛЕНИЯ СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

1316 411 H91

VALVE ASSEMBY, STEERING

SN: P090001-UP

1шт.

1

NSS

HOUSING, VALVE

SN: P090001-UP

1шт.

2

1206 757 H1

COVER, END

SN: P090001-UP

1шт.

|$3

25 492 R1

BOLT, HEX - 5/16NCx7/8

SN: P090001-UP

6шт.

|$4

120 214

WASHER, LOCK - 5/16

SN: P090001-UP

6шт.

3

662 398 C3

GASKET, REAR

SN: P090001-UP

1шт.

4

444 613

PLUG, PORT

SN: P090001-UP

2шт.

5

1316 490 H1

COVER, FRONT

SN: P090001-UP

1шт.

|$8

25 751 R1

BOLT, HEX - 5/16NCx1-1/4

SN: P090001-UP

4шт.

|$9

120 214

WASHER, LOCK - 5/16

SN: P090001-UP

4шт.

6

742 980 C1

BODY, CHECK BALL

SN: P090001-UP

2шт.

7

17 007 R1

BALL, CHECK - 7/32IN DIA.

SN: P090001-UP

2шт.

8

1220 721 H1

BALL, PLUG - 9/32IN DIA.

SN: P090001-UP

1шт.

9

1266 594 H1

BALL, PLUG - 3/16IN DIA.

SN: P090001-UP

1шт.

10

742 940 C2

SPRING, SPOOL

SN: P090001-UP

1шт.

11

738 356 C1

SHIM

SN: P090001-UP

-2шт.

12

742 946 C2

POPPET, SPOOL

SN: P090001-UP

1шт.

13

NSS

SPOOL, BRAKE

SN: P090001-UP

1шт.

14

738 373 C1

WASHER, SPRING

SN: P090001-UP

1шт.

15

738 346 C1

SPRING, INNER SPOOL

SN: P090001-UP

1шт.

16

738 351 C1

STOP, SPRING

SN: P090001-UP

1шт.

17

1200 120 H1

SPACER, SPRING

SN: P090001-UP

1шт.

18

1200 444 H1

STOP, OUTER SPRING

SN: P090001-UP

1шт.

19

662 403 C1

CAP, END

SN: P090001-UP

1шт.

20

625 421 C91

SEAL, CAP

SN: P090001-UP

1шт.

21

NSS

TUBE, PILOT

SN: P090001-UP

2шт.

22

1206 689 H1

RING, SEAL OUTER

SN: P090001-UP

3шт.

23

1206 688 H1

RING, SEAL INNER

SN: P090001-UP

1шт.

24

742 975 C1

SPRING, OUTER SPOOL

SN: P090001-UP

1шт.

25

615 007 C1

O-RING

SN: P090001-UP

2шт.

26

20 702 R1

PIN, DOWEL

SN: P090001-UP

2шт.

27

NSS

SPOOL, METERING

SN: P090001-UP

2шт.

28

NSS

SLEEVE, SPOOL

SN: P090001-UP

2шт.

29

1316 413 H1

CONNECTOR

SN: P090001-UP

2шт.

30

364 839 R1

O-RING

SN: P090001-UP

2шт.

31

1316 497 H1

PLUG, ORIFICE

SN: P090001-UP

2шт.

|$36

-1шт.

|$37

F1 VALVE IS SUPPLIED WITH FOUR PLUGS. TWO ARE REMOVED FOR THE STEERING DIAGNOSTIC LINES.

-1шт.

|$38

-1шт.
