Запчасти Komatsu D87E-2 FIG. F-A РУЛЕВ. УПРАВЛЕНИЕ ПРИВОД - TWO SPEED КЛАПАН КРЕПЛЕНИЕ СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

1316 460 H91

VALVE AND CONTROLS

SN: P090001-UP

1шт.

1

VALVE, STEERING (SEE FIG. F2305-03A1)

SN: P090001-UP

1шт.

2

661 931 C2

PIN, LINK

SN: P090001-UP

2шт.

|$3

103 373

PIN, COTTER

SN: P090001-UP

2шт.

|$5

OR

-1шт.

|$7

30 259 R1

PIN, COTTER

SN: P090001-UP

2шт.

3

661 976 C1

SHAFT, LEVER

SN: P090001-UP

1шт.

4

19 711 R1

PIN, SPRING

SN: P090001-UP

1шт.

|$10

629 040 C92

LEVER ASSEMBLY, STEERING

SN: P090001-UP

1шт.

5

661 899 C2

LEVER, STEERING

SN: P090001-UP

1шт.

6

634 099 C91

BEARING, SEALED

SN: P090001-UP

2шт.

|$14

OR

-1шт.

|$16

661 892 C91

BEARING, SEALED

SN: P090001-UP

2шт.

7

109 461

FITTING, LUBE

SN: P090001-UP

1шт.

8

740 545 C1

LEVER, STEERING

SN: P090001-UP

2шт.

9

1207 303 H1

BRACKET, LEVER

SN: P090001-UP

1шт.

|$20

25 751 R1

BOLT, HEX - 5/16NCx1-1/4

SN: P090001-UP

3шт.

|$21

120 214

WASHER, LOCK - 5/16

SN: P090001-UP

3шт.

10

661 905 C1

LINK, LEVER TO VALVE

SN: P090001-UP

6шт.

|$23

1209 937 H1

BOLT, HEX

SN: P090001-UP

5шт.

|$24

26 317 R1

BOLT, HEX - 1/2NCx1-1/4

SN: P090001-UP

5шт.

|$25

120 384

WASHER, LOCK - 1/2

SN: P090001-UP

10шт.

11

666 267 C1

STUD, MANIFOLD

SN: P090001-UP

3шт.

|$27

25 534 R1

WASHER, FLAT - 3/8

SN: P090001-UP

3шт.

|$28

120 382

WASHER, LOCK - 3/8

SN: P090001-UP

3шт.

|$29

25 522 R1

NUT, HEX - 3/8NC

SN: P090001-UP

3шт.

12

GASKET, MANIFOLD (SEE FIG. F2300-18A0)

SN: P090001-UP

1шт.

13

MANIFOLD, VALVE (SEE FIG. F2300-23A0)

SN: P090001-UP

1шт.

|$32

-1шт.

|$33

F1 PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$34

-1шт.
