Запчасти Komatsu D87E-2 FIG. F-A РУЛЕВ. УПРАВЛЕНИЕ УПРАВЛ-ЕS - TWO SPEED СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

1316 421 H91

STEERING CONTROLS - STEER/TRANS

SN: P090001-UP

1шт.

|$1

1316 355 H91

BRACKET W.BEARINGS, VALVE MTG

SN: P090001-UP

1шт.

1

1316 343 H91

BRACKET

SN: P090001-UP

1шт.

2

126 152

FITTING, LUBE

SN: P090001-UP

1шт.

3

740 465 C91

BEARING

SN: P090001-UP

2шт.

|$6

OR

-1шт.

|$8

740 466 C91

BEARING

SN: P090001-UP

2шт.

4

1316 305 H91

HOUSING, STEER/TRANS VALVE

SN: P090001-UP

2шт.

|$10

1316 442 H1

BOLT, BUTTON - M10x30

SN: P090001-UP

4шт.

|$11

30 176 R1

WASHER - M10

SN: P090001-UP

4шт.

|$12

1316 443 H1

BOLT, HEX - M6x20

SN: P090001-UP

2шт.

|$13

30 325 R1

WASHER, FLAT - M6

SN: P090001-UP

2шт.

|$14

30 208 R1

NUT, HEX - M6

SN: P090001-UP

2шт.

|$15

1316 449 H1

WASHER

SN: P090001-UP

2шт.

5

1297 756 H1

CLEVIS

SN: P090001-UP

1шт.

|$17

16 619 R1

PIN

SN: P090001-UP

1шт.

|$18

103 384

PIN, COTTER

SN: P090001-UP

1шт.

6

BOOT, LEVER (SEE FIG. F2305-02A0)

SN: P090001-UP

1шт.

7

1308 476 H91

RETAINER, BOOT

SN: P090001-UP

1шт.

|$21

1316 443 H1

BOLT, HEX - M6x20

SN: P090001-UP

4шт.

|$22

30 325 R1

WASHER, FLAT - M6

SN: P090001-UP

4шт.

8

1303 390 H1

PLATE

SN: P090001-UP

1шт.

|$24

24 860 R1

BOLT

SN: P090001-UP

2шт.

|$25

25 536 R1

WASHER

SN: P090001-UP

2шт.

9

VALVE, STEERING (SEE FIG. F2305-03A1)

SN: P090001-UP

1шт.

|$27

666 267 C1

BOLT

SN: P090001-UP

3шт.

|$28

120 382

WASHER

SN: P090001-UP

3шт.

|$29

25 534 R1

WASHER

SN: P090001-UP

3шт.

|$30

25 522 R1

NUT

SN: P090001-UP

3шт.

10

ROD, STEERING (SEE FIG. F2305-04A0)

SN: P090001-UP

1шт.

|$32

16 617 R1

PIN

SN: P090001-UP

1шт.

|$33

103 374

PIN, COTTER

SN: P090001-UP

1шт.

11

BELLCRANK (SEE FIG. F2305-05A0)

SN: P090001-UP

1шт.

12

300 486 R1

SPRING

SN: P090001-UP

1шт.

13

1500 517 H91

SUPPORT, SHAFT

SN: P090001-UP

1шт.

|$37

30 022 R1

BOLT

SN: P090001-UP

4шт.

|$38

30 184 R1

WASHER

SN: P090001-UP

4шт.

14

1500 522 H1

SHAFT, BELLCRANK

SN: P090001-UP

1шт.

|$40

19 795 R1

PIN

SN: P090001-UP

1шт.

15

ROD, BRAKE (SEE FIG. F2305-06A0)

SN: P090001-UP

1шт.

|$42

16 617 R1

PIN

SN: P090001-UP

2шт.

|$43

103 374

PIN, COTTER

SN: P090001-UP

2шт.

16

1298 672 H91

BELLCRANK, BRAKE

SN: P090001-UP

1шт.

|$45

30 021 R1

BOLT

SN: P090001-UP

1шт.

|$46

728 660 C1

KEY

SN: P090001-UP

1шт.

17

1298 829 H91

PAWL

SN: P090001-UP

1шт.

|$48

30 209 R1

WASHER

SN: P090001-UP

3шт.

|$49

103 362

PIN, COTTER

SN: P090001-UP

3шт.

18

1298 826 H1

SPRING

SN: P090001-UP

1шт.

19

1298 823 H91

ROD, BRAKE LOCK

SN: P090001-UP

1шт.

20

109 390

GROMMET

SN: P090001-UP

1шт.

21

737 460 C1

KNOB

SN: P090001-UP

1шт.

22

1298 828 H1

GUIDE, BRAKE LOCK

SN: P090001-UP

1шт.

|$55

30 193 R1

BOLT

SN: P090001-UP

2шт.

|$56

30 210 R1

WASHER

SN: P090001-UP

2шт.

23

1500 788 H91

SUPPORT, PEDAL

SN: P090001-UP

1шт.

|$58

30 021 R1

BOLT

SN: P090001-UP

4шт.

|$59

30 168 R1

NUT

SN: P090001-UP

4шт.

|$60

30 176 R1

WASHER

SN: P090001-UP

4шт.

|$61

740 465 C91

BEARING, NEEDLE

SN: P090001-UP

2шт.

|$62

OR

SN: P090001-UP

-1шт.

|$63

740 466 C91

BEARING, NEEDLE

SN: P090001-UP

2шт.

|$64

109 461

FITTING, LUBE

SN: P090001-UP

1шт.

24

1500 528 H91

PEDAL, BRAKE

SN: P090001-UP

1шт.

|$66

1501 155 H1

BOLT

SN: P090001-UP

1шт.

|$67

30 168 R1

NUT

SN: P090001-UP

1шт.

25

1298 363 H91

CONNECTOR, FLEXIBLE

SN: P090001-UP

1шт.

26

1298 958 H91

BRACKET

SN: P090001-UP

1шт.

27

14X-43-12110

CAP, BRAKE PEDAL

SN: P090001-UP

1шт.

28

BRACKET (SEE FIG. F2305-07A0)

SN: P090001-UP

1шт.

|$72

30 003 R1

BOLT

SN: P090001-UP

2шт.

|$73

30 175 R1

WASHER

SN: P090001-UP

2шт.

29

300 486 R1

SPRING

SN: P090001-UP

1шт.

30

1500 218 H1

BRACKET

SN: P090001-UP

1шт.

31

1316 336 H91

HANDREST

1шт.

|$77

1316 442 H1

BOLT, BUTTON - M10x30

SN: P090001-UP

3шт.

|$78

30 176 R1

WASHER, FLAT - M10

SN: P090001-UP

3шт.

32

1309 014 H1

PLATE, BOOT RETAINER

SN: P090001-UP

1шт.

33

HANDLE ASSY (SEE FIG. F2305-02A0)

SN: P090001-UP

1шт.

34

VALVE, TASC (SEE FIG. F2305-08A0)

SN: P090001-UP

1шт.

|$82

24 840 R1

BOLT, HEX - 3/8NCx1

SN: P090001-UP

3шт.

|$83

25 534 R1

WASHER, FLAT - 3/8

SN: P090001-UP

3шт.

35

LEVER, SAFETY (SEE FIG. F2305-09A0)

SN: P090001-UP

1шт.

36

1316 531 H1

INSULATION

SN: P090001-UP

1шт.

37

1316 533 H1

INSULATION

SN: P090001-UP

1шт.

38

1316 532 H1

INSULATION

SN: P090001-UP

1шт.

39

1316 530 H1

INSULATION

SN: P090001-UP

1шт.

40

RATCHET (SEE FIG. K2110-01A0)

SN: P090001-UP

1шт.

|$90

-1шт.

|$91

F1 PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$92

-1шт.
