Запчасти Komatsu D87E-2 FIG. F-A РУЛЕВ. УПРАВЛЕНИЕ ПРИВОД - TWO SPEED RETAINER И COVER СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

679 217 C91

RETAINER AND COVER

SN: P090001-UP

2шт.

1

659 839 C1

RETAINER, BRAKE PLATE

SN: P090001-UP

2шт.

2

25 546 R1

WASHER, FLAT - 1/2

SN: P090001-UP

24шт.

3

275 635 R1

BOLT, HEX - 1/2NCx3

SN: P090001-UP

8шт.

4

659 838 C1

COVER, RETAINER

SN: P090001-UP

2шт.

5

25 505 R1

BOLT, HEX - 1/2NCx1-3/8

SN: P090001-UP

16шт.

6

364 885 R1

SEAL, RING

SN: P090001-UP

2шт.

7

709 803 C1

PLUG, PORT

SN: P090001-UP

2шт.

|$9

OR

-1шт.

|$11

9410 360

PLUG, PORT

SN: P090001-UP

2шт.

8

24 867 R1

BOLT, HEX - 1/2NCx3-1/2

SN: P090001-UP

16шт.

9

25 546 R1

WASHER, FLAT - 1/2

SN: P090001-UP

16шт.

10

RETAINER, BRAKE (SEE FIG. F2300-19A0)

SN: P090001-UP

2шт.

|$15

679 216 C91

RETAINER AND COVER

SN: P090001-UP

2шт.

11

659 902 C2

RETAINER, BRAKE PLATE

SN: P090001-UP

2шт.

12

659 838 C1

COVER, RETAINER

SN: P090001-UP

2шт.

13

25 546 R1

WASHER, FLAT - 1/2

SN: P090001-UP

16шт.

14

25 505 R1

BOLT, HEX - 1/2NCx1-3/8

SN: P090001-UP

16шт.

15

709 803 C1

PLUG, PORT

SN: P090001-UP

2шт.

|$22

OR

-1шт.

|$24

9410 360

PLUG, PORT

SN: P090001-UP

2шт.

16

364 885 R1

SEAL, RING

SN: P090001-UP

2шт.

17

24 867 R1

BOLT, HEX - 1/2NCx3-1/2

SN: P090001-UP

24шт.

18

25 546 R1

WASHER, FLAT - 1/2

SN: P090001-UP

24шт.

19

RETAINER, BRAKE (SEE FIG. F2300-19A0)

SN: P090001-UP

2шт.

|$29

-1шт.

|$30

F1 PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$31

-1шт.

|$32

-1шт.

|$33

F2 OPTIONAL DESIGN WITH EACH OTHER.

-1шт.

|$34

-1шт.
