Запчасти Komatsu D87E-2 FIG. F-A ГИДРОТРАНСФОРМАТОР И PRESSURE ФИЛЬТР. ТРУБЫ СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

1

PUMP, CHARGE/SCAVENGE (SEE FIG. F2300-27A0)

SN: P090001-UP

1шт.

2

296 247 R1

O-RING

SN: P090001-UP

1шт.

3

9411 109

ELBOW

SN: P090001-UP

1шт.

4

1235 100 H1

HOSE

SN: P090001-UP

1шт.

5

1298 160 H91

BRACKET

SN: P090001-UP

1шт.

|$5

24 862 R1

BOLT

SN: P090001-UP

4шт.

|$6

25 536 R1

WASHER

SN: P090001-UP

4шт.

|$7

116 121

WASHER

SN: P090001-UP

4шт.

6

307 915 R1

O-RING

SN: P090001-UP

2шт.

7

306 132 C2

STRAP

SN: P090001-UP

-2шт.

8

FILTER, PRESSURE (SEE FIG. F2300-09A0)

SN: P090001-UP

1шт.

|$11

25 228 R1

BOLT

SN: P090001-UP

4шт.

|$12

116 120

WASHER

SN: P090001-UP

4шт.

9

347 765 R1

CONNECTOR

SN: P090001-UP

1шт.

10

1316 483 H1

HOSE

SN: P090001-UP

1шт.

11

308 872 R1

CLIP

SN: P090001-UP

1шт.

|$16

24 839 R1

BOLT

SN: P090001-UP

1шт.

|$17

115 093

WASHER

SN: P090001-UP

1шт.

12

666 268 C1

TEE

SN: P090001-UP

1шт.

13

296 247 R1

O-RING

SN: P090001-UP

2шт.

14

VALVE, PRES. REG. (SEE FIG. F2320-11A0)

SN: P090001-UP

1шт.

15

1298 166 H1

HOSE

SN: P090001-UP

1шт.

16

9410 283

ELBOW

SN: P090001-UP

1шт.

17

9410 205

CONNECTOR

SN: P090001-UP

1шт.

18

368 269 R1

O-RING

SN: P090001-UP

1шт.

19

VALVE ASSY, HI-LO (SEE FIG. F2300-38A0)

SN: P090001-UP

1шт.

20

28 071 R1

CONNECTOR

SN: P090001-UP

1шт.

21

1210 977 H1

ELBOW

SN: P090001-UP

1шт.

22

1500 812 H1

HOSE

SN: P090001-UP

1шт.

23

9410 981

ELBOW

SN: P090001-UP

1шт.

24

296 247 R1

O-RING

SN: P090001-UP

1шт.

25

CONVERTER, TORQUE (SEE FIG. F2310-01A0)

SN: P090001-UP

1шт.

26

736 983 C1

HOSE, CHAFING

SN: P090001-UP

1шт.

27

306 132 C2

STRAP

SN: P090001-UP

4шт.

28

308 872 R1

CLIP

SN: P090001-UP

2шт.

|$35

24 839 R1

BOLT

SN: P090001-UP

2шт.

|$36

115 093

WASHER

SN: P090001-UP

2шт.

|$37

102 635

NUT

SN: P090001-UP

2шт.

29

9410 260

ELBOW

SN: P090001-UP

1шт.

30

1316 404 H1

ELBOW

SN: P090001-UP

1шт.

31

307 915 R1

O-RING

SN: P090001-UP

1шт.

32

9402 865

ELBOW, 3/8 NPTx3/4-16

SN: P090001-UP

1шт.

33

VALVE ASSY, NEUTRAL START SOLENOID (SEE FIG. F2300-37A0)

SN: P090001-UP

1шт.

|$43

275 804 R1

BOLT

SN: P090001-UP

2шт.

|$44

25 544 R1

WASHER

SN: P090001-UP

2шт.

34

1316 406 H1

HOSE

SN: P090001-UP

1шт.

35

1208 027 H1

ELBOW

SN: P090001-UP

1шт.

36

369 751 R1

O-RING

SN: P090001-UP

1шт.

37

380 632 R1

CONNECTOR

SN: P090001-UP

2шт.

38

368 269 R1

O-RING

SN: P090001-UP

2шт.

39

347 765 R1

CONNECTOR, REDUCER

SN: P090001-UP

2шт.

40

307 915 R1

O-RING

SN: P090001-UP

2шт.

41

1316 485 H1

HOSE

SN: P090001-UP

1шт.

42

9410 976

ELBOW

SN: P090001-UP

1шт.

43

364 839 R1

O-RING

SN: P090001-UP

1шт.

44

VALVE, REGULATOR (SEE FIG. F2300-39A0)

SN: P090001-UP

1шт.

|$56

24 845 R1

BOLT

SN: P090001-UP

2шт.

|$57

25 544 R1

WASHER

SN: P090001-UP

2шт.

|$58

1316 482 H1

BAR, VALVE MOUNTING

SN: P090001-UP

1шт.

45

667 931 C1

HOSE

SN: P090001-UP

1шт.

46

444 613

PLUG

SN: P090001-UP

1шт.

47

1316 484 H1

HOSE

SN: P090001-UP

1шт.

48

HOSE, CHAFING - 4 IN. LONG

SN: P090001-UP

1шт.

49

TEE (SEE FIG. F2320-01A1)

SN: P090001-UP

2шт.

50

O-RING (SEE FIG. F2320-01A1)

SN: P090001-UP

3шт.

51

CONNECTOR (SEE FIG. F2320-01A1)

SN: P090001-UP

1шт.

52

HOSE (SEE FIG. F2320-01A1)

SN: P090001-UP

1шт.

53

TEE (SEE FIG. J2100-03A0)

SN: P090001-UP

1шт.

|$68

-1шт.

|$69

F1 CUT FROM BULK HOSE 364 360 C1.

-1шт.

|$70

-1шт.
