Запчасти Komatsu SA6D125E-3D КОЛЕНВАЛ (№-) КОЛЕНВАЛ

|$0

6151-35-1010

Crankshaft Assembly

SN: 324065-UP

1шт.

1

Crankshaft

SN: 324065-UP

1шт.

2

6150-35-1120

Gear

SN: 324065-UP

1шт.

3

6150-31-1130

Key

SN: 324065-UP

1шт.

|$4

6150-21-8010

Main Metal Assembly, Standard

SN: 324065-UP

7шт.

|$5

6150-29-8010

Main Metal Assembly, Undersize 0.25mm

SN: 324065-UP

7шт.

|$6

6150-28-8010

Main Metal Assembly, Undersize 0.50mm

SN: 324065-UP

7шт.

|$7

6150-27-8010

Main Metal Assembly, Undersize 0.75mm

SN: 324065-UP

7шт.

|$8

6150-26-8010

Main Metal Assembly, Undersize 1.00mm

SN: 324065-UP

7шт.

4

Metal, Standard

SN: 324065-UP

1шт.

4

Metal, Undersize 0.25mm

SN: 324065-UP

1шт.

4

Metal, Undersize 0.50mm

SN: 324065-UP

1шт.

4

Metal, Undersize 0.75mm

SN: 324065-UP

1шт.

4

Metal, Undersize 1.00mm

SN: 324065-UP

1шт.

5

Metal, Standard

SN: 324065-UP

1шт.

5

Metal, Undersize 0.25mm

SN: 324065-UP

1шт.

5

Metal, Undersize 0.50mm

SN: 324065-UP

1шт.

5

Metal, Undersize 0.75mm

SN: 324065-UP

1шт.

5

Metal, Undersize 1.00mm

SN: 324065-UP

1шт.

6

6150-21-8050

Metal Assembly, Standard

SN: 324065-UP

1шт.

6

6150-29-8050

Metal Assembly, Oversize 0.25mm

SN: 324065-UP

1шт.

6

6150-28-8050

Metal Assembly, Oversize 0.50mm

SN: 324065-UP

1шт.

6

6150-27-8050

Metal Assembly, Oversize 0.75mm

SN: 324065-UP

1шт.

6

6150-26-8050

Metal Assembly, Oversize 1.00mm

SN: 324065-UP

1шт.

6

Metal, Thrust Standard

SN: 324065-UP

3шт.

6

Metal, Thrust Oversize 0.25mm

SN: 324065-UP

3шт.

6

Metal, Thrust Oversize 0.50mm

SN: 324065-UP

3шт.

6

Metal, Thrust Oversize 0.75mm

SN: 324065-UP

3шт.

6

Metal, Thrust Oversize 1.00mm

SN: 324065-UP

3шт.

|$0

6151-35-1010

Crankshaft Assembly

SN: 324065-UP

1шт.

1

Crankshaft

SN: 324065-UP

1шт.

2

6150-35-1120

Gear

SN: 324065-UP

1шт.

3

6150-31-1130

Key

SN: 324065-UP

1шт.

|$4

6150-21-8010

Main Metal Assembly, Standard

SN: 324065-UP

7шт.

|$5

6150-29-8010

Main Metal Assembly, Undersize 0.25mm

SN: 324065-UP

7шт.

|$6

6150-28-8010

Main Metal Assembly, Undersize 0.50mm

SN: 324065-UP

7шт.

|$7

6150-27-8010

Main Metal Assembly, Undersize 0.75mm

SN: 324065-UP

7шт.

|$8

6150-26-8010

Main Metal Assembly, Undersize 1.00mm

SN: 324065-UP

7шт.

4

Metal, Standard

SN: 324065-UP

1шт.

4

Metal, Undersize 0.25mm

SN: 324065-UP

1шт.

4

Metal, Undersize 0.50mm

SN: 324065-UP

1шт.

4

Metal, Undersize 0.75mm

SN: 324065-UP

1шт.

4

Metal, Undersize 1.00mm

SN: 324065-UP

1шт.

5

Metal, Standard

SN: 324065-UP

1шт.

5

Metal, Undersize 0.25mm

SN: 324065-UP

1шт.

5

Metal, Undersize 0.50mm

SN: 324065-UP

1шт.

5

Metal, Undersize 0.75mm

SN: 324065-UP

1шт.

5

Metal, Undersize 1.00mm

SN: 324065-UP

1шт.

6

6150-21-8050

Metal Assembly, Standard

SN: 324065-UP

1шт.

6

6150-29-8050

Metal Assembly, Oversize 0.25mm

SN: 324065-UP

1шт.

6

6150-28-8050

Metal Assembly, Oversize 0.50mm

SN: 324065-UP

1шт.

6

6150-27-8050

Metal Assembly, Oversize 0.75mm

SN: 324065-UP

1шт.

6

6150-26-8050

Metal Assembly, Oversize 1.00mm

SN: 324065-UP

1шт.

6

Metal, Thrust Standard

SN: 324065-UP

3шт.

6

Metal, Thrust Oversize 0.25mm

SN: 324065-UP

3шт.

6

Metal, Thrust Oversize 0.50mm

SN: 324065-UP

3шт.

6

Metal, Thrust Oversize 0.75mm

SN: 324065-UP

3шт.

6

Metal, Thrust Oversize 1.00mm

SN: 324065-UP

3шт.
